Поз.
Артикул
Описание
4
BATTERY12 V/115 AH
4
BATTERY12V/120 AH
4
BATTERY , Replaced By: A0035418801
8
MOUNTING FRAME BATTERY
9
INSULATING PLATE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
10
SPACER TUBE BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
11
SCREW PIPE ELBOW TO BRACKET M 10X50
11
SCREW , Replaced By: N304017010053
11
SCREW , Replaced By: N304017010030
12
WASHER STRUT TO CROSS MEMBER
12
WASHER , Replaced By: N007349010007
13
NUT STRAP TO BRACKET
13
NUT , Replaced By: N910113010000
14
BRACKET BATTERY MOUNTING,5 928008 FROM IDENT NO. 5 928009 SEE SA 46975
16
SPACER TUBE BATTERY MOUNTING,5 928008 FROM IDENT NO. 5 928009 SEE SA 46975
18
WASHER
20
SCREW BATTERY MOUNTING M 8X260X40
24
RAIL. BATTERY BASE FRAME
28
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
28
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
28
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
28
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
28
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
29
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
30
NEG. CABLE ALTERNATOR GROUND STRAP TO SIDE MEMBER
32
CLAMPING PIECE BATTERY POS. POLE
36
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
40
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
44
CABLE SHOE BATTERY CABLE 10-70 MM
44
CABLE SHOE BATTERY CABLE 10-70 MM
44
CABLE SHOE BATTERY CABLE 10-70 MM
46
CABLE SHOE BATTERY CABLE 12-70 MM
46
CABLE SHOE BATTERY CABLE 12-70 MM
46
CABLE SHOE BATTERY CABLE 12-70 MM
48
CABLE LUG WITH BORE 8.4MMX70MM2
52
LOOM TIE LINE MOUNTING
71
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
71
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
71
SCREW BRACKET TO SIDE MEMBER
72
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
74
WASHER BRACKET TO CAB REAR PANEL
74
WASHER BRACKET TO LEFT SIDE MEMBER
78
NUT
82
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
82
SCREW , Replaced By: N910105010009
86
WASHER RADIATOR TO RUBBER MOUNTING
86
WASHER , Replaced By: N000125010532
90
NUT EXHAUST PIPE TO SIDE MEMBER
91
CLAMP LINE MOUNTING
92
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
92
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
92
SCREW BRACKET TO SIDE MEMBER
93
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
93
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
93
NUT , Replaced By: N913004008001
94
SWITCH (BATTERY MASTER SWITCH),5 447531
98
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
98
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
98
SCREW BRACKET TO SIDE MEMBER
102
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
102
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
102
NUT , Replaced By: N913004008001
106
BRACKET LINE MOUNTING
110
SCREW BRACKET TO BRACKET
110
SCREW , Replaced By: N910142008001
114
WASHER BRACKET TO CAB REAR PANEL
114
WASHER BRACKET TO LEFT SIDE MEMBER
118
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
120
CLAMP BRAKE HOSE BRACKET
126
CLAMPING PIECE BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
130
SCREW ELECTRIC CABLE TO BRACKET
134
WASHER COMPRESSED AIR LINE TO BRACKET
999
BRACKET ALTERNATOR BRANCH-OFF TO ALTERNATOR BRACKET
999
CABLE CONNECTOR1.5-6.6 MM2
999
NUT AT FILTER BRACKET
999
NUT BRACKET TO BRACKET
999
NUT BRACKET TO BEARING BRACKET
999
NUT BALL SOCKET TO ROD
999
NUT BATTERY CABLE
999
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
999
SCREW AT FILTER BRACKET
999
SCREW HOSE TO CAB M 6X25
999
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X50
999
SCREW BRACKET TO CROSS MEMBER M 8X45
999
CABLE HARNESS MASKED STOP LAMP, SUPPLIED LOOSE
999
PLUG TO PLUG THE BORES
999
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
999
BRACKET BATTERY CABLE TO ENGINE MOUNTING
999
SCREW BRACKET TO COVERING
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW
999
SCREW , Replaced By: N000000001145
999
INSULATING HOSE6 X 0.6 MM, ORDER BY THE METER
999
CABLE SHOE6 - 25 MM
999
CABLE SHOE NEG. CABLE
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
PLUG ROCKER PANEL
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
ELECTRIC CABLE FROM BATTERY TO BATTERY SUPPORT, ORDER BY THE METER
