Поз.
Артикул
Описание
100
HOUSING
160
GASKET SHIFT CASE TO TRANSMISSION
170
BUSH WITHOUT CHAMFER SHIFT CASE TO TRANSMISSION
180
SEALING RING
190
NEEDLE ROLLER BEARING
200
BUSH WITHOUT CHAMFER SHIFT CASE TO TRANSMISSION
210
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
220
WASHER , Replaced By: N000125008443
230
SELECTOR SHAFT
240
SHIFT DOG SHIFT CASE TO TRANSMISSION
250
LOCK SHIFTING DOG
260
GEARSHIFT LEVER
270
BALL JOINT
300
CLOSING COVER
310
NUT
310
CLAMP NUT , Replaced By: A0009905160
320
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
330
BREATHER , Replaced By: A3432640089
340
SELECTOR SHAFT
350
SELECTOR LEVER
360
RING SEGMENT SHIFT CASE TO TRANSMISSION
370
SELECTOR LEVER
390
PROTECTIVE COVERING
400
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
410
CLAMP NUT
420
COVER
430
GASKET TRANSMISSION CASE,BOTTOM
440
SCREW CLAMP TO EXHAUST PIPE AND TO FLEXIBLE METAL TUBE M 8X25
