Поз.
Артикул
Описание
192
PROPELLER SHAFT ,032936
192
PROPELLER SHAFT ,032935
193
GREASE NIPPLE
193
GREASE NIPPLE , Replaced By: N071412008102
216
SUPPORTING SLEEVE ,032936
216
SUPPORTING SLEEVE , UP TO FRONT AXLE 033066
217
LOCK WASHERROCKINGER TYP 59 G140,59 G150
218
SCREW BRACKET TO REAR AXLE
218
SCREW BRACKET TO ENGINE MOUNTING
218
SCREW , Replaced By: N308676016015
238
SEAL RING FUEL LINE TO FEED PUMP
239
FITTING
240
LINE
242
DOUBLE TAPER RING
243
NUT. UNION NUT LINE CONNECTION
244
SEAL RING FUEL LINE TO FEED PUMP
245
LOCK
246
HOLLOW SCREW
248
RING ,032936
248
RING , UP TO FRONT AXLE 033066
250
WHEEL HUB ,032936
250
WHEEL HUB , UP TO FRONT AXLE 033066
251
OIL COLLECTOR ,032936
251
OIL COLLECTOR ,032935
253
TAPERED ROLLER BEARING INSIDE, UP TO FRONT AXLE 033858 UP TO REAR AXLE 024806 EXCEPT FOR 023200-023622 OR UP TO CHASSIS 705597 EXCEPT FOR 695068,695154,695171,695303,695351,695572,695743,695747,695849,695937,696468,696496,696656,696659, 696661,696682,697031,697082,698906.
254
SPACER RING
256
SEAL RING , FROM FRONT AXLE 056688
256
SEAL RING
257
TAPERED ROLLER BEARING OUTSIDE
259
WHEEL MOUNTING BOLT
259
WHEEL MOUNTING BOLT , UP TO FRONT AXLE 033858 UP TO REAR AXLE 024806 EXCEPT FOR 023200-023622 OR UP TO CHASSIS 705597 EXCEPT FOR 695068,695154,695171,695303,695351,695572,695743,695747,695849,695937,696468,696496,696656,696659, 696661,696682,697031,697082,698906.
261
NUT REAR SUBFRAME
263
LOCK , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
264
FOLLOWER ,032936
264
FOLLOWER ,032935
266
LOCK RING52X2 MM
266
LOCK RING , UP TO FRONT AXLE 033066
267
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
268
SCREW MOUNTING TO CONSOLE M 14X35
268
SCREW , Replaced By: N308676014008
271
SEAL RING63X2 MM,032936
272
SCREW ,032936
999
RUBBER SECTION , UP TO FRONT AXLE 033066
999
THRUST WASHER , UP TO FRONT AXLE 033066
999
COVER , UP TO FRONT AXLE 033066, Replaced By: A3463375330, +001A3463375080
999
FLANGE FOR LEFT FRONT AXLE JOINT,032935
999
FLANGE RIGHT FRONT AXLE JOINT, UP TO FRONT AXLE 033066
999
NUT
999
OIL BAFFLE , UP TO FRONT AXLE 033066
999
THRUST WASHER
999
BUSHING , UP TO FRONT AXLE 033066
999
SCREW PLUG , UP TO REAR AXLE 051432
999
LOCK THRUST WASHER TO PROPELLER SHAFT, UP TO FRONT AXLE 033066
999
SCREW , UP TO FRONT AXLE 32935
999
STEERING ARM , UP TO FRONT AXLE 4 063693, Replaced By: A3433380205, +001A3433300503, +001A3433380206
999
SEAL HOLDER
999
KING PIN KINGPIN, FROM AXLE 4 035016
999
KING PIN , Replaced By: A3363300065, +001A3433320006, +001A0059816305, +001N915046012100
999
STEERING ARM LEFT
999
STEERING ARM , FROM AXLE 4 035016 UP TO FRONT AXLE 4 058051, Replaced By: A3433380501, +001A3434601405, +001A3434630601
999
REPAIR KIT DIFFERENTIAL GEAR
999
BUSHING TOP
999
HOUSING , UP TO AXLE 4 035015, Replaced By: A3463305214, +002A3433300019, +001A3433380501, +003N007346018000, +006N914112014001, +002N914112014300, +004N914112014301
999
HOUSING , UP TO AXLE 4 035015, Replaced By: A3463305314, +002A3433300019, +012N914112014001
999
HOUSING LEFT FRONT AXLE JOINT
999
JOINT HEAD LEFT
999
COVER LEFT
999
COVER LEFT
999
PIVOT PIN BRAKE SHOE BEARING, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIER KIT049764 UP TO CHASSIS 4 311018 ALSO INSTALLED ON 500001-535803,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535804-599999 SEE 731.8
999
NUT ,063279
999
COTTER PINTO 360 320 01 89
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINTO 000 429 16 30
999
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
NUT , Replaced By: N308673020002
999
SCREW CLAMP, TWO-HOLE
999
ROLL PIN. CLAMPING SLEEVE
999
WOODRUFF KEY BEARING BODY,6 900042
999
CLAMPING SLEEVE STEERING ARM AND KING PIN TO HOUSING
999
NUT , Replaced By: N308674020000
999
NUT REAR SPRING TO REAR AXLE
999
PLUG
999
LINE COUPLING
999
LINE COUPLING
999
LOOM TIE HAND PUMP
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
NUT SUPPORT TO SIDE MEMBER
