Поз.
Артикул
Описание
3
T-FITTING COMPRESSED AIR VALVE CONNECTION
3
T-FITTING COMPRESSED AIR VALVE CONNECTION
5
VALVE
5
VALVE (OVERFLOW VALVE)
5
VALVE , Replaced By: A0014295244
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
10
O-RING CHECK VALVE TO AIR RESERVOIR
12
THRUST RING CHECK VALVE TO AIR RESERVOIR
12
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
14
NUT CHECK VALVE TO AIR RESERVOIR
16
SEAL RING LINE CONNECTION
18
ELBOW FITTING AT OVERFLOW VALVE
34
LINE
34
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
34
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
34
LINE , Replaced By: A0004296201
36
TS DOUBLE FITTING SOLENOID VALVE
36
TS DOUBLE FITTING SOLENOID VALVE
36
FITTING , Replaced By: A0029906071
36
FITTING , Replaced By: A0039979072
36
DOUBLE FITTING , Replaced By: A0019972872
38
FITTING , Replaced By: A0009907171
38
ELBOW FITTING LINE CONNECTION, UP TO CHASSIS 4 329112,FROM CHASSIS SEE SA 25 009
44
UNION NUT
46
GLAND , Replaced By: A0019901667
46
SEAL CONE
48
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
48
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
50
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
52
SEAL RING LINE CONNECTION
54
DOUBLE FITTING , Replaced By: A0019972872
54
FITTING , Replaced By: A0039979072
54
FITTING , Replaced By: A0029906071
54
TS DOUBLE FITTING SOLENOID VALVE
56
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
58
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
74
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342101
74
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
74
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
74
VALVE , Replaced By: A0004342301
74
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
76
HANDLETO 000 434 23 01
78
CUP , Replaced By: A0004340486
78
CUPTO 000 434 10 01
78
CUP 3/2-WAY VALVE WABCO
78
CUP 3/2-WAY VALVE WABCO
90
REPAIR KIT 3/2-WAY VALVE BOSCH
90
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
90
REPAIR KIT 3/2-WAY VALVE WABCO
90
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 427
90
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 428
92
WASHER , Replaced By: N001440027000
92
WASHER VALVE TO BRACKET
92
WASHER VALVE TO BRACKET
92
WASHER OPERATING VALVE TO SIDE MEMBER SHELL
98
NUT , Replaced By: N080705026003
98
NUT 3/2-WAY VALVE TO CAB,4 685151
98
NUT 3/2-WAY VALVE TO CAB,4 685151
102
BRACKET
104
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
106
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
108
SCREW PIPE CLAMP
108
SCREW , Replaced By: N304017008021
110
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
112
NUT
114
TS DOUBLE FITTING SOLENOID VALVE
114
FITTING , Replaced By: A0029906071
114
FITTING , Replaced By: A0039979072
116
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
116
SCREW PLUG , Replaced By: N000908012009
116
SCREW PLUGROCKINGER,TYP 59 U150
116
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
118
SEAL RING LINE CONNECTION
120
BRACKET CONTROL COCK TO BRACKET, 832700
122
SCREW BRACKET TO CAB CROSS MEMBER
124
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
126
NUT BALL PIVOT TO LEVER
128
CONTROL COCK
140
CONSOLE
142
CONSOLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3604302011
142
CONSOLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3604302111
142
LEVER
142
LEVER
144
PIN DOUBLE LEVER TO PUSH ROD
146
WASHER , Replaced By: N000433010510
146
WASHER VIBRATION ABSORBER TO BRACKET
148
YOKE
150
LEVER
152
BUSHING OPERATING VALVE
154
PIN LEVER
156
WASHER , Replaced By: N000433010510
156
WASHER VIBRATION ABSORBER TO BRACKET
162
ROLLER LEVER
164
PIN , Replaced By: N007341005108
164
RIVET LEVER
166
CLIP LEVER
168
SCREW CLUTCH PEDAL
172
NUT
174
BRACKET DOUBLE LEVER TO PUSH ROD
176
SCREW CLAMP TO BRACKET AND TO PIPE
178
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
180
NUT
182
VALVE , Replaced By: A0004340301, +001N074305026202
182
VALVE , Replaced By: A0004340601, +001N074305026202
182
VALVE ADDITIONAL GEAR CLUSTER ACTUATION BOSCH
182
VALVE , Replaced By: A0004342201
182
VALVE GEAR CLUSTER SHIFT
184
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
184
REPAIR KIT 3/2-WAY VALVE WABCO
186
SEAL RING LINE CONNECTION
188
DOUBLE FITTING , Replaced By: A0019972872
188
FITTING , Replaced By: A0039979072
188
FITTING , Replaced By: A0029906071
188
TS DOUBLE FITTING SOLENOID VALVE
190
BRACKET TWO-WAY VALVE
190
BRACKET TWO-WAY VALVE
192
SCREW END PIECE TO EXHAUST PIPE M 10X25
192
SCREW REAR EXHAUST PIPE TO MUFFLER
192
SCREW BRACKET TO SIDE MEMBER
200
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
202
NUT BRACKET TO SUPPORT AND TO END PIECE
204
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
204
ADAPTER FITTING , Replaced By: A0039972072
206
SEAL RING LINE CONNECTION
208
VALVE
210
REPAIR KIT
210
REPAIR KIT
212
ELBOW FITTING AT OVERFLOW VALVE
214
THRUST RING CHECK VALVE TO AIR RESERVOIR
214
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
216
O-RING CHECK VALVE TO AIR RESERVOIR
218
NUT CHECK VALVE TO AIR RESERVOIR
228
TS DOUBLE FITTING SOLENOID VALVE
228
FITTING , Replaced By: A0029906071
228
FITTING , Replaced By: A0039979072
228
DOUBLE FITTING , Replaced By: A0019972872
230
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
230
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
232
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
238
CLAMP LINE MOUNTING
240
SCREW COVER PLATE TO BRACKET
242
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
246
NUT BALL PIVOT TO LEVER
248
CLAMP LINE MOUNTING
248
CLAMP , Replaced By: A3609950101
250
CLAMP LINE MOUNTING
250
CLAMP BRAKE LINE TO SIDE AND CROSS MEMBERS
252
SCREW HOOK TO BRACKET
252
SCREW , Replaced By: N007985005175
254
LOCK WASHER BRACKET TO STEERING COLUMN END
256
NUT IN CASE OF SUBSEQUENT INSTALLATION
256
NUT , Replaced By: N304032005005
258
CLAMP
260
PLATE LINE MOUNTING
262
SCREW CONTACTOR
264
LOCK WASHER BRACKET TO STEERING COLUMN END
266
NUT IN CASE OF SUBSEQUENT INSTALLATION
266
NUT , Replaced By: N304032005005
268
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
270
SCREW BRACKET TO CROSS CONNECTION STRUT
270
SCREW , Replaced By: N304017008034
272
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
276
NUT
278
CLAMP LINE MOUNTING
280
SCREW PROTECTION PLATE TO BRACKET
282
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
284
NUT BALL PIVOT TO LEVER
290
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
290
CLAMP ,K 147121, Replaced By: N000000000319
290
CLAMP , Replaced By: N916016008200
292
SCREW PROTECTION PLATE TO BRACKET
294
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
296
NUT BALL PIVOT TO LEVER
302
CLAMP SENSOR CABLE TO BRACKET
304
SCREW HOOK TO BRACKET
304
SCREW , Replaced By: N007985005175
306
LOCK WASHER BRACKET TO STEERING COLUMN END
308
NUT IN CASE OF SUBSEQUENT INSTALLATION
308
NUT , Replaced By: N304032005005
310
BRACKET HEATING WATER LINE
340
SHAFT
342
FITTED WASHER , USED WITH AIR BRAKE
344
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
352
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
354
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
354
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
354
SCREW , Replaced By: N304017008016
999
DIAPHRAGMTO 344 429 73 44
999
DIAPHRAGM
999
REPAIR KITTO 003 429 02 44
999
STRAINERTO 000 434 21 01
999
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
999
BUSHINGTO 000 434 10 01
999
VALVE , Replaced By: A0004342401
999
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH, OPTIONAL WITH 000 434 08 01
999
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
999
VALVE , Replaced By: A0004342601
999
VALVE"WESTINGHOUSE"
