Поз.
Артикул
Описание
5
BELL HUB WITH PLANETARY CARRIER,V 307324
5
PLANETARY GEARING RATIO: 1:4.000,V 207287
5
PLANETARY GEARING1:3.429,V 307324
5
PLANETARY GEARING RATIO: 1:4.000
5
PLANETARY GEAR DRIVE RATIO: 1:4.000,V 207287
5
PLANETARY GEAR DRIVE RATIO: 1:3.429,V 207324V 496300
5
PLANETARY GEARING RATIO: 1:3.429
5
PLANETARY GEARING RATIO: 1:3.429,V 207324, Replaced By: A9423501809
5
PLANETARY GEARING RATIO: 1:4.000,V 207287, Replaced By: A9423501609
6
BELL HUB WITH PLANETARY CARRIER, LKW W 972500, BUS W974541, V 000001, Replaced By: A0003500633
6
BELL HUB WITH PLANETARY CARRIER,393260
6
BELL HUB WITH PLANETARY CARRIER,V033854
6
BELL HUB WITH PLANETARY CARRIER,V 207287
6
BELL HUB WITH PLANETARY CARRIER, LKW W 972500, BUS W974541, V 000001
6
BELL HUB WITH PLANETARY CARRIER
6
BELL HUB WITH PLANETARY CARRIER,V033854
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
11
THRUST WASHER PLANET GEAR
14
THRUST WASHER PLANET GEAR
17
NEEDLE PLANET GEAR
17
NEEDLE BEARING NEEDLES, SET50 PIECES
17
NEEDLE
20
PIN PLANET GEAR
20
PIN PLANET GEAR
26
THRUST WASHER PLANET GEAR
26
SPACER WASHER , Replaced By: A3553540162
32
PLANET GEAR PARTS KIT
32
PLANET GEAR PARTS KIT,V 496484
32
PLANET GEAR PARTS KIT
32
PLANET GEAR PARTS KIT,393260
35
WHEEL HUB STEEL VERSION
35
WHEEL HUB STEEL VERSION
35
WHEEL HUB STEEL VERSION
35
WHEEL HUB CAST VERSION
35
WHEEL HUB STEEL VERSION
44
TAPERED ROLLER BEARING WHEEL HUB, OUTSIDE
44
TAPERED ROLLER BEARING OUTSIDE
44
TAPERED ROLLER BEARING WHEEL HUB, OUTSIDE
44
TAPERED ROLLER BEARING OUTSIDE
44
TAPERED ROLLER BEARING WHEEL HUB, OUTSIDE
44
TAPERED ROLLER BEARING OUTSIDE
44
TAPERED ROLLER BEARING WHEEL HUB, OUTSIDE
47
OIL COLLECTOR
47
OIL BAFFLE WHEEL HUB, OUTSIDE
47
OIL COLLECTOR WHEEL HUB, OUTSIDE TO 346 356 28 01/29 01
47
OIL COLLECTOR
47
OIL COLLECTOR AT REAR WHEEL HUB
53
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
53
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
53
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
53
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
53
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
56
COVER PLATE WHEEL HUB, INSIDE
56
COVER PLATE WHEEL BEARING
59
RADIAL SHAFT SEALING RING WHEEL HUB, OUTSIDE, ORDER ADDITIONALLY: A 013 997 89 46
59
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 015 997 90 45
86
THRUST RING WHEEL BEARING
86
THRUST RING , Replaced By: A3463561415
89
OUTSIDE GEAR PLANETARY GEAR TRAIN,NUMBER OF TEETH: 75,V 207287
89
OUTSIDE GEAR ,V 307324
89
OUTSIDE GEAR NUMBER OF TEETH: 85
89
OUTSIDE GEAR ,V 207287V 496879 FROM REAR AXLE V 496880, SEE STANDARD MICROFICHE
89
OUTSIDE GEAR ,V 307324
89
OUTSIDE GEAR NUMBER OF TEETH: 85
92
SUPPORT OUTSIDE GEAR
92
SUPPORT OUTSIDE GEAR
95
WIRE RING OUTSIDE GEAR TO SUPPORT
98
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
98
REAR AXLE SHAFT LESS INTERLOCK SERRATIONS
98
REAR AXLE SHAFT , Replaced By: A6583571401, +001N009045050001
98
REAR AXLE SHAFT , Replaced By: A6583571501, +001N009045050001
101
LOCK PLATE WHEEL HUB TO AXLE JOURNAL
104
GROOVED NUT HUB AND SUPPORT TO AXLE CASING
104
GROOVED NUT WHEEL HUB TO REAR AXLE TUBE
107
SNAP RING
110
LOCK RING INTERMEDIATE SHAFT BEARING
110
LOCK RING45X1.75 MM
113
SUN GEAR PLANETARY GEAR TRAIN,NUMBER OF TEETH: 25,V 207287
113
SUN GEAR NUMBER OF TEETH: 35,V 307324
113
SUN GEAR NUMBER OF TEETH: 35
113
SUN GEAR NUMBER OF TEETH: 25,V 207287
116
THRUST WASHER PLANET GEAR
119
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 1.00 MM
119
SPACER WASHER AS REQUIRED 0.50 MM, MAN AXLE
119
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.10 MM
119
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.20 MM
119
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.80 MM
119
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 1.50 MM
122
LOCK RING THRUST WASHER TO BELL HUB
125
WHEEL MOUNTING BOLT DISC WHEEL ON WHEEL HUB
125
WHEEL MOUNTING BOLT INTERMEDIATE PIECE TO REAR AXLE
125
WHEEL MOUNTING BOLTTO 385 356 01 01, ON EVERY AXLE,ONLY HUBS HAVING THE SAME PART NUMBER SHOULD BE INSTALLED
125
WHEEL MOUNTING BOLT LIGHT-ALLOY-SHEET DISC WHEEL, Replaced By: A0004013771
125
WHEEL MOUNTING BOLTTO 385 356 01 01, MINOR REPAIRS, Replaced By: A0004014071
128
CAPSCREW W HEXAL. DRIVE BRACKET TO PUMP M12X25
128
SCREW SUPPORT TO JOINT HOUSING M 14X35
131
SEAL RING PLANETARY GEAR TRAIN TO REAR WHEEL HUB
131
SEAL RING PLANETARY GEAR TRAIN TO WHEEL HUB
131
SEAL RING PLANETARY GEAR TRAIN TO REAR WHEEL HUB
131
SEAL RING , Replaced By: A0169974048
134
HUB CAP BELL HUB
134
END COVER ,006379 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3463340320, +002A3559970232, +002N007603045100
137
GASKET COVER TO BELL HUB, MAN AXLE
137
GASKET COVER TO HUB
140
SCREW COVER TO BELL HUB M 10X28
140
SCREW COVER TO BELL HUB
143
SCREW PLUG OIL DRAIN
146
SEALING RING. SEAL RING OIL DRAIN
149
SCREW PLUG
149
SCREW PLUG , Replaced By: A2109970132
149
SCREW PLUG OIL FILLING
152
SEALING RING OIL FILLING
161
DS WHEEL HUB WHEEL HUB
161
DS WHEEL HUB WHEEL HUB
161
REPAIR KIT WHEEL HUB, ONLY APPLICABLE TO MODELS: 748.271
161
REPAIR KIT WHEEL HUB, Replaced By: A9403501535
999
WHEEL MOUNTING BOLT DISC WHEEL ON WHEEL HUB
999
SEAL RING INFLATION PRESSURE CONTROL SYSTEM
999
REAR AXLE SHAFT , Replaced By: A6583571301, +001N009045050001
999
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS,W 972499
999
WHEEL MOUNTING BOLT DISC WHEEL ON WHEEL HUB, Replaced By: A0004013271
999
REAR AXLE SHAFT LESS INTERLOCK SERRATIONS,W 972499
