Поз.
Артикул
Описание
8
SEAL RING HOUSING,FRONT
8
SEAL RING OUTSIDE
11
SEAL RING HOUSING,FRONT
11
SEAL RING OUTSIDE
14
SEAL RING HOUSING,BOTTOM
14
SEAL RING HOUSING,BOTTOM
17
SEAL RING OUTSIDE
17
SEAL RING HOUSING,BOTTOM
20
SPACER WASHER AS REQUIRED 0.10 MM
20
SPACER WASHER AS REQUIRED 0.15 MM
23
BALL BEARING HOUSING,INSIDE
23
BALL BEARING HOUSING,INSIDE
23
BALL BEARING , Replaced By: N000625036212
23
GROOVED BALL BEARING , Replaced By: A0059815925
26
LOCK RING DISC SUPPORT
92
COUPLING FLANGE TRANSFER CASE INPUT 180 MM
92
COUPLING FLANGE TRANSMISSION 180 MM, FROM TRANSFER CASE 011191
95
COUPLING FLANGE FRONT AXLE OUTPUT 150 MM, FROM TRANSFER CASE 011191
95
COUPLING FLANGE FRONT AXLE OUTPUT 150 MM
95
COUPLING FLANGE FRONT AXLE OUTPUT 150 MM, UP TO TRANSFER CASE 011190
98
HEXAGON HEAD BOLT TRAILER COUPLING TO REAR CROSS MEMBER M20X1.5X80
98
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
98
HEXAGON HEAD BOLT FOLLOWER FLANGE TO PROPELLER SHAFT M16X1.5X55
98
SCREW , Replaced By: N308676020025
101
THRUST WASHER FOLLOWER FLANGE TO PROPELLER SHAFT
101
THRUST WASHER FOLLOWER FLANGE TO PROPELLER SHAFT
104
HEXAGON HEAD BOLT. SCREW PROPELLER SHAFT TO TRANSMISSION
104
SCREW , Replaced By: N308676014010
107
HEXAGON HEAD BOLT COUPLING FLANGE
107
SCREW PROPELLER SHAFT TO REAR AXLES I AND II
125
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
128
SEAL RING LINE CONNECTION
137
SCREW PLUG, FILLING HOUSING,BOTTOM
140
SEAL RING PNEUMATIC VALVE
173
SCREW PLUG , Replaced By: A0009972632
176
SCREW PLUG HOUSING,BOTTOM,183596
176
SCREW PLUG HOUSING,BOTTOM,183596
179
UNIT IDENTIFICATION PLATE P.T.O.
179
UNIT IDENTIFICATION PLATE , Replaced By: A6755841024
182
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
999
VIBRATION ABSORBER COUPLING FLANGE
