Поз.
Артикул
Описание
10
WOODEN FLOOR CENTRAL FRONT
20
WOODEN FLOOR CENTRAL
80
WOODEN FLOOR RIGHT CENTRAL
90
WOODEN FLOOR RIGHT REAR
100
WOODEN FLOOR RIGHT CENTRAL
110
REAR FLOOR COVERING LEFT CENTRAL
110
WOODEN FLOOR LEFT CENTRAL
120
WOODEN FLOOR CENTRAL FRONT
150
HANDLE RECESS CENTRAL FLOOR
160
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X20
170
WASHER BRACKET TO CAB REAR PANEL
180
PROTECTIVE STRIP FRONT FLOOR, 7J05QFT900A1800 ALUMINUM ANODIZED
185
COUNTERSUNK WOOD SCREW4,1X16MM
190
PROTECTIVE STRIP REAR FLOOR, 7J05QFT900A1800 ALUMINUM ANODIZED
195
COUNTERSUNK WOOD SCREW4,1X16MM
210
MOUNTING RAIL FRONT FLOOR, 7J05QFT900A1800 ALUMINUM ANODIZED
220
MOUNTING RAIL FRONT FLOOR, 7J05QFT900A1800 ALUMINUM ANODIZED
230
COUNTERSUNK WOOD SCREW4X12 T20
240
COUNTERSUNK WOOD SCREW4X12 T20
300
COVER ENTRANCE SLIDING DOOR RIGHT, 9E80QFT900A0010 BLACK
310
HEXALOBULAR BOLT BRACKET TO CONSOLE M6X16,V 224423
320
HEXALOBULAR BOLT ROCKER PANEL M6X60
330
COVER LOAD COMPARTMENT SLIDING DOOR ENTRANCE, 9E80QFT900A0010 BLACK
340
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
350
TREENAIL BRACKET TO FIRE WALL
360
COVER ENTRANCE SLIDING DOOR RIGHT, 9E80QFT900A0010 BLACK
370
COVER STRIP REAR ENTRANCE, TO BE ADAPTED DURING ASSEMBLY
390
COVER ENTRANCE SLIDING DOOR RIGHT, 8J06QFT900A0400 STONE
400
COVER STRIP REAR, 9E80QFT900A0010 BLACK
410
TREENAIL PLATE TO BODY
420
COVER INNER TRUNK SILL, 9E80QFT906A0001 BLACK
430
COVER OUTER TRUNK SILL, 9E80QFT906A0001 BLACK
