Mercedes A0005454626 - Розетка

214, 208CDI, 211CDI, 213CDI FROM IDENT-NR. R337627, 5337627, A901274 901.662

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 095 RELAY,FUSEBOX AND CONTROL MODULES IN SEAT FRAME IL. 4

Поз.
Артикул
Описание
3
A0008206858
SIGNAL LAMP YELLOW
3
A0008206658
SIGNAL LAMP BLUE
5
A0018226510
LENS
5
A0018226610
LENS BLUE
8
A0008223088
REFLECTOR , WHEN REPLACED FOR THE FIRST TIME,THE ENGINE MUST ALSO BE CHANGED
11
A0008292501
SERVOMOTOR12V
11
A0008290401
MOTOR12V, Replaced By: A0008292501
14
A0079971392
V-BELT
17
N000000000268
BULBH1-12V 55W
18
A0009970381
GROMMET3.0 MM
19
A0075458226
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
19
A0075458826
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 0.5-1.0 MM2
19
A0005454626
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
20
A9018200182
CONSOLE
23
N913024006101
RIVET NUT. RIVETED NUT GRIP RAIL MOUNTING
26
N304017006020
SCREW LICENSE PLATE TO BRACKET
29
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
29
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
32
A6739870041
RUBBER RING
35
N007985005505
SCREW REFLECTOR TO UNDERRUN PROTECTION
38
A9018200032
CLAMP
