Поз.
Артикул
Описание
20
ELECTRIC CABLE ENGINE CABLE HARNESS
25
PLUG HOUSING HEATER FLANGE CONNECTOR COVER
30
PIN BUSHING HOUSING. PLUG 4-POLE
35
PLUG HOUSING
40
PLUG CAP
45
NUT FROM ELECTRICAL COMPARTMENT TO CONTROL UNIT,SENSOR,ABS SOLENOID VALVE
50
PLUG SOCKET. PIN BUSHING
55
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
60
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
65
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
70
PIN BUSHING HOUSING BIPOLAR TO 651 540 36 09
75
PLUG CONNECTION FOR CONSTANTLY-OPEN THROTTLE VALVE
80
PLUG HOUSING. PLUG BIPOLAR
85
PLUG CAP
95
PLUG HOUSING 4-POLE
105
WIRE SEAL GREY 0.5-1.0 MM2
110
NUT. CLAMPING RING
115
BOOT 90-DEGREE OUTLET FOR CORRUGATED TUBE 10 MM
120
SOCKET HOUSING
147
BOOT BIPOLAR
148
BOOT 3-POLE
149
BOOT HEATER FLANGE CONNECTOR COVER
150
CONTACT BUSHING1.0-2.5 MM
150
CONTACT BUSHINGTO 904 150 24 33/2.5-4.0MM
150
CONTACT BUSHING0.25-0.5 MM
150
CONTACT BUSHING
152
PIN BUSHING HOUSING LAMP UNIT, FRONT RIGHT (BLACK) 3-PIN,SLK2.8,E2
155
PIN BUSHING HOUSING WITH FIFTY-FOUR PINS,ABS ELEKTRONIK
157
LOCKING BRACKET PARTS KIT TO A004 545 04 26
157
CLAMP PARTS KIT TO 004 545 04 26, Replaced By: A0005451986
160
CAP PIN BUSHING HOUSING,FIFTY-FOUR PIN
165
FLAT PLUG WITH DETENT AND WITH CATCH FOR HOUSING 0,5 - 1,0 MM2
165
PLUG SOCKET. FLAT PLUG CONTACT SURFACE SILVER-PLATED 3.8 , 1.5 - 2.5
170
CABLE SEAL. GASKET CONTROL-UNIT PLUG-CONNECTION
170
CLAMP. GASKET OIL LEVEL SENSOR
175
GASKET , P 718187 R 000001
175
GASKET LIGHT BLUE 8 MM
175
GASKET WITHE 8 MM
180
STOP PLUG. PLUG CONTROL-UNIT PLUG-CONNECTION
190
CABLE SHOE
197
DISTRIBUTOR I.D.: 10/10/7,5
