Поз.
Артикул
Описание
10
11
BATTERY SUPPORT BATTERY/APPARATUS
12
13
14
BATTERY CASE
16
17
18
19
23
29
SHIM BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER 13 MM
35
35
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M14X1.5X100
35
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M14X1.5X110
35
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X50
35
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X45
35
HEXAGON HEAD BOLT. SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES M14X1,5X80,D 228766
35
HEXAGON HEAD BOLT. SCREW SPACER TUBE TO BRACKET M 14X1.5X100
35
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X60
41
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
41
NUT SUPPORT TO FRAME
41
HEXAGON NUT BRACKET TO SPARE WHEEL CARRIER M16X1.5
41
NUT BRACKET TO SIDE MEMBER M12X1.5
47
SCREW SUPPORT TO FRAME M 14X1.5X160
47
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X60
48
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
48
SCREWM 10X20
48
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
53
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
59
FASTENING CLAMP BATTERY/APPARATUS SUPPORT
59
LOCKING HANDLE PROTECTIVE PLATE TO APPARATUS SUPPORT
59
LOCKING HANDLE BATTERY/APPARATUS SUPPORT, Replaced By: A9609880142
65
RIVET LOCKING LEVER TO BATTERY/APPARATUS SUPPORT
65
RIVET LOCKING LEVER TO BATTERY/APPARATUS SUPPORT
71
COVER BATTERY COVER, Replaced By: A9305410103
72
119
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
119
NUT HORN TO BRACKET M8
119
NUT BATTERY,XB209706
191
192
203
SCREW 3/2-WAY VALVE TO BRACKET
203
SCREW SOLENOID VALVE TO BRACKET M 8X180
203
HEXAGON HEAD BOLT. SCREW VIBRATION ABSORBER TO BRACKET M 10X65
203
SCREW CHARGING AIR INTERCOOLER TO RADIATOR M10 X 180
224
HEXALOBULAR BOLT LINE MOUNTING M6 X 25
224
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
335
335
WASHER BRACKET TO CAB REAR PANEL
350
NUT BRACKET TO SIDE MEMBER
350
NUT , Replaced By: N913023006001
350
NUT. HEXAGON NUT STRAP TO CONSOLE M12X1.5
350
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
350
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
350
NUT BRACKET TO SIDE MEMBER M12X1.5
350
NUT , Replaced By: N913023010002
