Поз.
Артикул
Описание
32
35
41
47
55
60
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
62
SWITCH BATTERY CUT-OFF
62
SWITCH BATTERY CUT-OFF
65
KEY
68
BRACKET SWITCH TO BATTERY SUPPORT
71
SCREW BRACKET AND CLAMP M6X20
74
NUT BRACKET TO FIRE WALL
81
SCREW. HEXAGON HEAD BOLT LINE MOUNTING M6X70
81
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
82
SCREW , Replaced By: N914146006102
84
SCREW BATTERY CABLE TO BRACKET M6X45
86
NUT BRACKET TO FIRE WALL
86
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
92
GROMMET BATTERY CABLE TO SIDE MEMBER,LEFT
92
GROMMET LINE THRU FRAME 25/19/8 MM
93
CLAMP ELECTRIC CABLE MOUNTING
94
CLAMP CABLE HARNESS TO BRACKET
95
COVERING BATTERY CUT-OFF,D 262514
98
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
98
LOOM TIE ELECTRIC CABLE MOUNTING
102
WASHER , Replaced By: A3609902340
107
SPACER RING BATTERY CABLE
112
