Поз.
Артикул
Описание
27
SCREW BRACKET TO SIDE MEMBER M10X35
27
HEXALOBULAR BOLT
28
STUD BOLTM10X20
32
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
32
NUT HEAT PROTECTION PLATE ON EXHAUST PIPE
101
THROTTLE HOUSING THROTTLE HOUSING TO FRONT EXHAUST PIPE
104
SHAFT THROTTLE HOUSING TO FRONT EXHAUST PIPE
110
BUSHING THROTTLE HOUSING TO FRONT EXHAUST PIPE
110
BUSHING THROTTLE VALVE SHAFT
113
VALVE THROTTLE HOUSING TO FRONT EXHAUST PIPE
116
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
119
NUT STRAP TO BRACKET
122
LEVER EXHAUST-BRAKE THROTTLE VALVE
125
BALL PIVOT
128
SCREW , Replaced By: N910105006005
131
NUT , Replaced By: N910112006001
135
CYLINDER , Replaced By: A0004305926
137
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
138
CIRCLIP ,B 884219
139
PIN INTERMEDIATE SPEED STOP
140
NUT LEVER TO SHIFTING SHAFT
141
BUSHING"WABCO"
142
WASHER PUMP TO CONSOLE
144
BRACKET POWER CYLINDER TO BRACKET
149
NUT HORN TO BRACKET M8
