Поз.
Артикул
Описание
10
BRACKET LEFT
10
BRACKET LEFT
10
BRACKET LEFT
30
BEARING BRACKET AT BRACKET
30
BEARING BRACKET AT BRACKET
45
WORM
45
WORM ,5 127459, Replaced By: A6204030085, +001A6204030683
45
WORM
45
WORM ,5 127459, Replaced By: A6204030085, +001A6204030683
50
CLAMPING SLEEVE CRANK TO BUSHING
55
STOP GEAR SPARE WHEEL CARRIER,5 127460
55
STOP GEAR ,5 127459, Replaced By: A6204030683, +001A6204030085
55
STOP GEAR SPARE WHEEL CARRIER,5 127460
55
STOP GEAR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE5 127459, Replaced By: A6204030283, +001A6204030085
55
STOP GEAR SPARE WHEEL CARRIER,5 127460
65
WASHER WORM AND SHAFT TO BRACKET
65
WASHER WORM AND SHAFT TO BRACKET
70
DISC SPRING WORM AND SHAFT TO BRACKET
70
DISC SPRING WORM AND SHAFT TO BRACKET
75
SCREW END PIECE TO EXHAUST PIPE M 10X25
75
SCREW REAR EXHAUST PIPE TO MUFFLER
75
SCREW END PIECE TO EXHAUST PIPE M 10X25
95
NUT , Replaced By: N910113010000
95
NUT STRAP TO BRACKET
100
WIRE CABLE. ROPE , ORDER BY THE METER, Replaced By: N083334008000
100
WIRE CABLE
105
BRACKET RIGHT
105
BRACKET RIGHT
105
BRACKET RIGHT
105
BRACKET RIGHT
105
BRACKET RIGHT
105
BRACKET RIGHT
105
BRACKET RIGHT
125
BRACKET SPARE WHEEL CARRIER
125
BRACKET AT BRACKET
125
BRACKET SPARE WHEEL CARRIER
125
BRACKET AT BRACKET
145
SCREW CONSOLE TO SIDE MEMBER
145
SCREW CONSOLE TO SIDE MEMBER
145
SCREW CONSOLE TO SIDE MEMBER
150
NUT SUPPORT TO SIDE MEMBER
150
NUT SUPPORT TO SIDE MEMBER
195
PLATE LEFT AND RIGHT CONSOLES TO FRAME
195
PLATE LEFT AND RIGHT CONSOLES TO FRAME
195
PLATE BRACKET TO FRAME
200
PLATE BRACKET TO FRAME
208
SHIM BRACKET TO FRAME
210
GUSSET PLATE LEFT AND RIGHT CONSOLES TO FRAME
210
GUSSET PLATE LEFT AND RIGHT CONSOLES TO FRAME
210
GUSSET PLATE LEFT AND RIGHT CONSOLES TO FRAME
212
SCREW , Replaced By: N308676014020
212
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
265
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
265
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
265
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
270
SCREW BRACKET TO CAB CONSOLE,K 035197
270
SCREW BRACKET TO CAB CONSOLE,K 035197
270
SCREW BRACKET TO CAB CONSOLE,K 035197
270
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
280
NUT , Replaced By: N910113014001
280
NUT BRACKET TO SIDE MEMBER
280
NUT BRACKET TO SIDE MEMBER
280
NUT BRACKET TO SIDE MEMBER
315
GUSSET PLATE LEFT AND RIGHT CONSOLES TO FRAME
315
GUSSET PLATE LEFT AND RIGHT CONSOLES TO FRAME
316
GUSSET PLATE GUSSET PLATE TO FRAME,RIGHT
316
GUSSET PLATE GUSSET PLATE TO FRAME,RIGHT
316
GUSSET PLATE GUSSET PLATE TO FRAME,RIGHT
318
PLATE BRACKET TO FRAME
318
PLATE RIGHT,AT FRAME
318
PLATE BRACKET TO FRAME
320
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
320
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
325
SCREW BRACKET TO CAB CONSOLE,K 035197
325
SCREW , Replaced By: N000961014064
325
SCREW BRACKET TO SIDE MEMBER
325
SCREW BRACKET TO CAB CONSOLE,K 035197
325
SCREW STEERING SUPPORT TO FRAME M 14X50
326
SCREW , Replaced By: N308676014020
326
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
330
NUT , Replaced By: N910113014001
330
NUT BRACKET TO SIDE MEMBER
330
NUT BRACKET TO SIDE MEMBER
330
NUT BRACKET TO SIDE MEMBER
331
WASHER , Replaced By: N000125015019
331
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
335
SCREW CONSOLE TO SIDE MEMBER
335
SCREW , Replaced By: N308676012026
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW CONSOLE TO SIDE MEMBER
335
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
335
SCREW CONSOLE TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
340
NUT SUPPORT TO SIDE MEMBER
345
SCREW CONSOLE TO SIDE MEMBER
350
NUT SUPPORT TO SIDE MEMBER
360
CRANK , Replaced By: A6504030045
360
CRANK , Replaced By: A6504030045
360
CRANK SPARE WHEEL HOIST 340MM
365
BASE BRACKET TO RIGHT SIDE MEMBER
370
SCREW BRACKET TO CAB CONSOLE,K 035197
375
CROSS MEMBER GUSSET PLATE TO CROSS MEMBER
375
CROSS MEMBER CROSS MEMBER TO GUSSET PLATE
375
CROSS MEMBER GUSSET PLATE TO CROSS MEMBER,4 909154
380
SCREW GUSSET PLATE TO CROSS MEMBER
380
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
380
SCREW BRACKET TO SIDE MEMBER
380
SCREW BRACKET TO SIDE MEMBER
380
SCREW BRACKET TO SIDE MEMBER
385
NUT , Replaced By: N910113014001
385
NUT BRACKET TO SIDE MEMBER
385
NUT BRACKET TO SIDE MEMBER
385
NUT BRACKET TO SIDE MEMBER
390
BRACKET SPARE WHEEL
390
BRACKET SPARE WHEEL
425
WASHER , Replaced By: N000125015019
425
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
425
WASHER SPARE WHEEL TO BRACKET
430
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
435
NUT , Replaced By: N308673014001
435
NUT BRACKET TO SIDE MEMBER,K 035196
438
SCREW , Replaced By: N000961014084
438
SCREW , Replaced By: N000961014148
438
SCREW FRONT SPRING REAR BRACKET TO SIDE MEMBER M 14X1.5X75
440
PROTECTIVE PLATE (HEAT SHIELD)
999
CLAMP , Replaced By: A3874900041
999
CLAMP EXHAUST MUFFLER TO BRACKET
999
WASHER LEFT AND RIGHT CONSOLES TO FRAME
999
SPACER SPARE WHEEL TO SPARE WHEEL WINCH, ONLY FOR USE WITH SA 32220/05 TO BE ADAPTED DURING ASSEMBLY
