Поз.
Артикул
Описание
4
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
10
BUSHING FRONT
10
BUSHING FRONT
12
SCREW (SPRING BOLT)
14
NUT , Replaced By: N910113014000
14
NUT STEERING SUPPORT TO FRAME
16
SPRING CLAMP FRONT SPRING,5 193395
24
SHIM SPRING LEAF
30
SCREW FOR SPRING CLAMPS
34
NUT SUPPORT TO SIDE MEMBER
36
SPACER TUBE SPRING CLAMP
39
RIVET SPRING CLAMP TO SPRING LEAF,5 940410
45
LINK TORSION BAR TO CONSOLE
48
SHACKLE. LINK TORSION BAR
57
SPACER WASHER SHACKLE TO BEARING BRACKET TO 699 320 01 78,02 78
57
SPACER WASHER SHACKLE TO BEARING BRACKET
66
BUSHING LINK TO CONSOLE, INAPPLICABLE TO IDENT NO.: 5 545417,5 545468,5 549721,5 549753,5 551382,5 553458,5 556586,5 556951,5 557200,5 568184,5 568795,5 575157,5 575986.K 054776
72
SCREW FLYWHEEL
78
NUT SUPPORT TO SIDE MEMBER
96
NUT SUPPORT TO SIDE MEMBER
99
NUT CONSOLE TO SUPPORT
99
NUT , Replaced By: N910113016001
135
BEARING TORSION BAR,LEFT,5 0251895 184731
135
BEARING TORSION BAR,RIGHT,5 0251895 184731
138
CONSOLE LEFT STABILIZER
138
CONSOLE LEFT STABILIZER
138
CONSOLE RIGHT STABILIZER
138
CONSOLE RIGHT STABILIZER
139
STUD BOLT
147
BEARING BRACKET TORSION BAR,FRONT
150
SCREW TORSION BAR TO BEARING BRACKET M 12X50,5 903514
156
NUT , Replaced By: N910113012003
156
NUT BEARING BRACKET TO SIDE MEMBER
156
NUT , Replaced By: N910113016001
156
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
156
NUT CONSOLE TO SUPPORT
222
BRACKET FRONT AXLE I SHOCK ABSORBER,LEFT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
222
BRACKET LEFT SHOCK ABSORBER,4 877630
222
BRACKET FRONT AXLE I SHOCK ABSORBER,RIGHT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
222
BRACKET RIGHT SHOCK ABSORBER
238
SHOCK ABSORBER , Replaced By: A0063230900
238
SHOCK ABSORBER , Replaced By: A0043239200
238
SHOCK ABSORBER , Replaced By: A0063230900
238
SHOCK ABSORBER FRONT AXLE
240
RUBBER BUFFER , Replaced By: A0003232885
240
RUBBER MOUNTINGTO 003 326 46 00
240
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
240
RUBBER BUFFER , Replaced By: A0003233144
240
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
242
BUSHINGTO 004 323 52 00
242
SPACER RINGTO 002 323 86 00,003 323 03 00,
261
PIN , Replaced By: A3893230074
261
CENTERING BOLT FRONT SPRINGS TO FRONT AXLE 28 MM
261
PIN FRONT SPRINGS TO FRONT AXLE 28 MM, Replaced By: A9303230374
261
PIN , Replaced By: A6573310074
270
PLATE FRONT SPRINGS TO FRONT AXLE
270
PLATE , Replaced By: A6483310026
270
PLATE FRONT SPRINGS TO FRONT AXLE
270
PLATE FRONT SPRINGS TO FRONT AXLE
270
SPACER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6483310026
270
PLATE , Replaced By: A6203310026
273
RUBBER BUFFER SPRING STOP
273
RUBBER BUFFER SPRING STOP
273
RUBBER BUFFER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6553310044
276
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
276
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
276
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
276
U-BOLT FRONT SPRINGS TO FRONT AXLE 290 MM
276
U-BOLT , Replaced By: A3363310025
276
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
285
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
999
PAD FRONT SPRINGS TO FRONT AXLE 7 MM
999
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
999
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
999
SHIM BETWEEN THE SPRING LEAVES 3 MM
999
CONSOLE ,5 9107605 910761, Replaced By: A6223230163, +001N000939014036
999
BEARING BRACKET
999
BUSHING SPRING EYE,FRONT
