Поз.
Артикул
Описание
5
CROSS MEMBER (REAR CROSS MEMBER), TO BE ADAPTED DURING ASSEMBLY
10
CROSS MEMBER (REAR CROSS MEMBER)
10
CROSS MEMBER , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3873120735
15
CROSS MEMBER (REAR CROSS MEMBER)
15
CROSS MEMBER , Replaced By: A6553120435
15
CROSS MEMBER
15
CROSS MEMBER (REAR CROSS MEMBER)
35
SHIM REAR CROSS MEMBER TO SIDE MEMBERS
50
REINFORCEMENT LEFT
50
REINFORCEMENT RIGHT
55
GUSSET PLATE LEFT
55
GUSSET PLATE RIGHT
75
STRUT REAR CROSS MEMBER
75
STRUT REAR CROSS MEMBER
75
STRUT REAR CROSS MEMBER
80
GUSSET PLATE REAR CROSS MEMBER TO RIGHT SIDE MEMBER
80
GUSSET PLATE REAR CROSS MEMBER TO LEFT SIDE MEMBER
135
WASHER CONSOLE TO REAR CROSS MEMBER
145
SCREW , Replaced By: N910105014010
145
SCREW SUPPORT TO SIDE MEMBER M14X40
145
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
145
SCREW GUSSET PLATE TO FRAME M 16X35
145
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 16X44,5 219681
150
WASHER CROSS MEMBER TO SUPPORT
155
NUT BRACKET TO REAR CROSS MEMBER
155
NUT STEERING SUPPORT TO FRAME
155
NUT PARTICLE FILTER M14
999
BUSHING SUPPORT TO SIDE MEMBER, SIMPLE PART-PLEASE HAVE SHOP MADE
999
ANGLE REAR CROSS MEMBER TO RIGHT SIDE MEMBER
999
ANGLE REAR CROSS MEMBER TO LEFT SIDE MEMBER
999
ANGLE RIGHT
999
ANGLE LEFT
999
REINFORCEMENT REAR CROSS MEMBER
999
REINFORCEMENT REAR CROSS MEMBER
999
REINFORCEMENT REAR CROSS MEMBER
999
REINFORCEMENT REAR CROSS MEMBER
999
REINFORCEMENT REAR CROSS MEMBER
