Поз.
Артикул
Описание
5
SWINGING LINK COMPLETE
9
CONSOLE LIFTING DEVICE USED FOR TRAILING AXLE, TO BE ADAPTED DURING ASSEMBLY
11
SWINGING LINK RIGHT
11
SWINGING LINK LEFT
14
AXLE TUBE
17
TAPERED ROLLER BEARING INSIDE
20
SEAL RING SWINGING LINK TO AXLE TUBE,INSIDE
23
THRUST RING SWINGING LINK TO AXLE TUBE,INSIDE
26
CYLINDR. ROLLER BEARING OUTSIDE
29
FLANGE SWINGING LINK
32
STUD
35
GASKET COVER TO SWINGING LINK
38
COVER SWINGING LINK
41
SCREW PLUG, FILLING HOUSING,BOTTOM
41
SCREW PLUG , Replaced By: N000000000648
41
PLUG , Replaced By: N000908010004
44
SCREWROCKINGER,TYP 59 U150
44
SCREW , Replaced By: A0009847929
47
SHACKLE RIGHT
47
SHACKLE LEFT
50
BUSHING SPRING SHACKLE TO SWINGING LINK
53
SEAL RING SPRING SHACKLE TO SWINGING LINK
56
SEAL RING SPRING SHACKLE TO SWINGING LINK
59
SCREW LEAF SPRING TO STRUT
62
NUT BRACKET TO FRAME
65
BUSHING LIFT ARM
68
RING LIFT ARM
71
GASKET LIFT ARM
107
STOP RIGHT
107
STOP LEFT
146
GREASE NIPPLE
149
SCREW RUBBER MOUNTING TO FRONT CONSOLE
152
WASHER SENSOR CABLE TO REAR AXLE,LEFT AND RIGHT
155
SCREW DETENT
158
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
158
SCREW , Replaced By: N308676016014
158
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
158
SCREW , Replaced By: N308676016004
158
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
158
SCREW , Replaced By: N308676016007
161
NUT CONSOLE TO SUPPORT
161
NUT , Replaced By: N910113016001
164
SCREW SWINGING LINK TO TRAILING AXLE
164
SCREW SWINGING LINK TO TRAILING AXLE
167
NUT CONSOLE TO SUPPORT
167
NUT , Replaced By: N910113016001
999
BRACKET , Replaced By: A6454310740
999
BRACKET , Replaced By: A4354922941
999
SCREW , Replaced By: A0019976130
