Поз.
Артикул
Описание
16
EXHAUST PIPE LEFT
16
EXHAUST PIPE LEFT
20
EXHAUST PIPE RIGHT
20
EXHAUST PIPE RIGHT
20
EXHAUST PIPE RIGHT
20
EXHAUST PIPE RIGHT
20
EXHAUST PIPE RIGHT
24
CLAMP SLIDING PIECE TO EXHAUST PIPE
24
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
28
SCREW EXHAUST PIPE TO SIDE MEMBER
32
NUT , Replaced By: N913023010002
32
NUT EXHAUST PIPE TO SIDE MEMBER
32
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
36
FITTING FROM EXHAUST PIPES TO EXHAUST MUFFLER
40
CONNECTOR IN FRONT OF EXHAUST MUFFLER
40
CONNECTOR IN FRONT OF EXHAUST MUFFLER
44
BRACKET EXHAUST MUFFLER TO CROSS MEMBER
44
BRACKET EXHAUST MUFFLER TO CROSS MEMBER
44
BRACKET BRACKET TO CROSS MEMBER
48
SCREW , Replaced By: N304017008018
48
SCREW SUPPORT TO FENDER
48
SCREW PUMP TO FRAME SIDE MEMBER M 8X40
48
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
52
WASHER , Replaced By: N000125008443
52
WASHER EXHAUST MUFFLER TO STRAP
56
NUT , Replaced By: N913004008001
56
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
NUT BRACKET TO BRACKET
56
NUT EXHAUST PIPE TO SIDE MEMBER
56
NUT , Replaced By: N913023010002
56
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
60
BRACKET FRONT EXHAUST PIPE,LEFT
60
BRACKET FRONT EXHAUST PIPE,RIGHT
64
SCREW SUPPORT TO SIDE MEMBER M14X40
64
SCREW SUPPORT TO SIDE MEMBER M14X40
64
SCREW BRACKET TO SIDE MEMBER
68
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
68
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
72
CLAMP , Replaced By: N071555124501
72
CLAMP END PIECE TO EXHAUST PIPE
76
CLAMP EXHAUST PIPE TO BRACKET
80
SCREW , Replaced By: N304017010002
80
SCREW EXHAUST PIPE TO SIDE MEMBER
80
SCREW EXHAUST PIPE TO SIDE MEMBER
80
SCREW BRACKET TO SIDE MEMBER
80
SCREW EXHAUST PIPE TO SIDE MEMBER
80
SCREW REAR EXHAUST PIPE TO MUFFLER
80
SCREW REAR EXHAUST PIPE TO MUFFLER
84
SCREW , Replaced By: N910105010011
84
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
88
NUT , Replaced By: N913023010002
88
NUT EXHAUST PIPE TO SIDE MEMBER
88
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
88
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
88
NUT EXHAUST PIPE TO SIDE MEMBER
88
NUT , Replaced By: N910113010000
88
NUT STRAP TO BRACKET
88
NUT STRAP TO BRACKET
97
EXHAUST MUFFLER
97
EXHAUST MUFFLER
97
EXHAUST MUFFLER
102
STRAP PARTS KIT
104
WASHER LEAF SPRING TO STRUT
108
NUT SUPPORT TO SIDE MEMBER
108
NUT STRAP TO SUPPORT
116
SUPPORT EXHAUST MUFFLER
116
SUPPORT EXHAUST MUFFLER
116
SUPPORT EXHAUST MUFFLER
120
SCREW , Replaced By: N308676014020
120
SCREW SUPPORT TO SIDE MEMBER M14X40
120
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
120
SCREW SUPPORT TO SIDE MEMBER M 14X1.5X42
120
SCREW , Replaced By: N910105014010
120
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
120
SCREW , Replaced By: A9429901304
120
SCREW APPARATUS SUPPORT TO FRAME
120
SCREW FRONT SPRING REAR BRACKET TO SIDE MEMBER M 14X1.5X65
120
SCREW SUPPORT TO SIDE MEMBER M 14X1.5X42
120
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
124
WASHER , Replaced By: N000125015019
124
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
128
NUT , Replaced By: N910113014001
128
NUT PARTICLE FILTER M14
128
NUT BRACKET TO SIDE MEMBER
128
NUT BRACKET TO SIDE MEMBER
168
PROTECTIVE PLATE , Replaced By: A6554901930
168
PROTECTIVE PLATE (HEAT SHIELD)
172
SCREW BUSHING AND LEVER TO CAB
172
SCREW HEAT SHIELD TO MUFFLER
184
PROTECTIVE PLATE FUEL TANK
184
PROTECTIVE PLATE REAR EXHAUST PIPE, NOT USED
188
CLAMP , Replaced By: N071555100501
188
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
188
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
192
SCREW , Replaced By: N304017010002
192
SCREW BRACKET TO SIDE MEMBER
192
SCREW REAR EXHAUST PIPE TO MUFFLER
196
NUT , Replaced By: N910113010000
196
NUT STRAP TO BRACKET
196
NUT STRAP TO BRACKET
999
BRACKET LEFT EXHAUST PIPE
999
COLLAR (SLIDING COLLAR)
999
BRACKET EXHAUST MUFFLER TO CROSS MEMBER
999
INTERMEDIATE PIECE INTERMEDIATE PIECE TO FRONT EXHAUST PIPE AND TO EXHAUST MUFFLER
999
BRACKET FRONT EXHAUST PIPE
999
STRUT
999
BRACKET FRONT EXHAUST PIPE
999
BRACKET RIGHT EXHAUST PIPE
999
PROTECTIVE PLATE (HEAT SHIELD)
999
SUPPORT (CONSOLE),FOR FENDER
999
BRACKET FENDER
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
