Поз.
Артикул
Описание
9
FRAME
15
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
20
SEAL
26
SEAL
31
CLIP
42
SEAL BOTTOM FRAME,FRONT
48
PAD
53
PAD LATERAL INSULATION
60
PAD REAR
65
PAD
71
HEADLINER , LIGHT GREY NO 7020 CODE 061,062,161,162,261,262,361,362,461,462,961,962,BAMBO,LIGHT-COLORED NO.8038 CODE 003,004,063,103,104,163,167,203,204,263,267,303,304,363 AND FOOTN. 15
83
BOW WITH SLIDING ROOF, 023 194993 033 066865 123 235194 130 228992 223 024765
88
CLIP
105
LOCK
117
STOP AT MOUNTING RAIL,LEFT
128
RAIL LEFT
144
SCREW
149
SEAL480 MM
159
SLIDING ROOF PLATE
159
SLIDING ROOF PLATE , Replaced By: A1237801821
191
SEAL
197
NUT RETAINER
197
NUT RETAINER , Replaced By: A0009909191
284
SCREW
322
PAD
397
COVER RAIL BOTTOM FRAME,FRONT, 023 049084 033 024844 123 034291 130 044426
403
SLIDING RAIL LEFT
403
SLIDING RAIL , Replaced By: A1237822526
409
SLIDING RAIL LEFT
415
SCREW
415
SCREW , Replaced By: A1409900436
432
FRAME , STATE COLOR NUMBER WHEN ORDERING
438
RUBBER SEAL LEATHER & IMITATION LEATHER 837 MM
443
CLIP
455
FASTENER BUTTON
460
HOSEWASSERABLAUF HINTEN 250 MM
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SHEET METAL SCREW
999
SHEET METAL SCREW FENDER TO BODY
999
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
TOOTHED WASHER , 123.020 082784 123.023 100522 123.026 050534 123.120 116041 123.123 080963 123.126 045537 123.130 101733
999
SCREW
999
NUT BALL PIVOT TO LEVER
999
NUT TACHOGRAPH TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW BRACKET TO AIR INTAKE PIPE
999
SCREW
999
SCREW SHUT-OFF VALVE TO BRACKET
999
RIVET
999
WASHER BOOT TO CAB FLOOR
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000433005304
999
WASHER BRACKET TO SUPPORT
999
WASHER , Replaced By: N000125004319
999
SLIDING RAIL RIGHT
999
COVER RAIL
999
CLIP , Replaced By: A0009888978
999
PAD , Replaced By: A1167820197
999
BRACKET FOR MOTOR AND GEARING
999
SLIDING SHOE
999
SLIDING RAIL , Replaced By: A1237822626
999
PAD HEIGHT ADJUSTMENT,RIGHT
999
STOP AT MOUNTING RAIL,RIGHT
999
RAIL RIGHT
999
SLIDING JAW , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 114.060 106899 114.062 104000 115.015 220900 115.017 014515 115.110 418986 115.115 225585 115.117 028441, Replaced By: A1157800183, +001A1157821912
999
ANGLE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 114.060 106899 114.062 104000 115.015 220900 115.017 014515 115.110 418986 115.115 225585 115.117 028441, Replaced By: A1157821912, +001A1157800183
999
ANGLE , Replaced By: A1157820012, +001A1157820130
999
ANGLE , Replaced By: A1157802712
999
ANGLE REAR RIGHT
999
ANGLE RIGHT
999
SLIDING JAW , 023 143560 033 058449 123 130866 130 149678
999
SLIDING RAIL RIGHT
999
COVER RAIL
999
GROMMET GEARING TO BRACKET
999
LOCK FRAME TO REINFORCEMENT FRAME
999
BUSHING MOTOR TO BRACKET
999
CLIP13 MM, Replaced By: A0129884678
999
FOAM PLASTICS FRONT ROOF RAIL
999
FOAM PLASTICS , Replaced By: A0009833598
