Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
8
SCREW SHOCK ABSORBER TO CONSOLE
14
STOP ACCELERATOR PEDAL
17
SCREW ACCELERATOR PEDAL
20
ROD ,082831
23
NUT , Replaced By: A0009906350
26
BRACKET SET POINT SENDER UNIT
29
SCREW COVER PLATE TO COVER PLATE M 6 X 12
32
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
35
DISTRIBUTOR
38
SENDER UNIT SUPPLY/BRAKE PRESSURE
41
SWITCH SUPPLY PRESSURE CONTROL
42
FITTING , Replaced By: A0039979072
44
SEAL RING 3/2-WAY VALVE
44
SEAL RING FRONT AXLE/REAR AXLE 3/2-WAY VALVE
47
SCREW PLUG WATER DRAIN
47
SCREW PLUG 3/2-WAY VALVE,CONNECTION:,5 363121
50
TS DOUBLE FITTING SOLENOID VALVE
51
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, M 12X1.5 / 6 MM, VOSS 230
53
SCREW BRACKET TO CROSS MEMBER
53
SCREW , Replaced By: N304014006004
56
SCREW , Replaced By: N304017008021
59
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
59
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
62
SCREW. UNION SCREW LINE CONNECTION
65
MUFFLER TRAILER CONTROL VALVE
999
RESERVOIR COMPRESSED AIR 10 L.
999
RESERVOIR COMPRESSED AIR 30 L
999
RESERVOIR PNEUMATIC SUSPENSION AIR RESERVOIR 40 L
999
BRAKE VALVEWABCO
999
ARTICULATION PIECE ACCELERATOR PEDAL
999
CONSOLE AIR RESERVOIR 10 L
999
COVERING BOTTOM,087672089587
999
LINE , NOT USED
999
COVERING TOP,087672089587
999
COVERING STEERING COLUMN PANELLING,087556
999
STEERING COLUMN BRACKET ,068088
999
STEERING SUPPORT (STEERING BRACKET)
999
PROTECTIVE SLEEVE STEERING COLUMN PANELLING
999
PITMAN ARM
999
PITMAN ARM , Replaced By: A3574633001
999
NUT , Replaced By: N304032008006
