Поз.
Артикул
Описание
54
BRACKET LINE MOUNTING
63
CLAMP LINE MOUNTING
63
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
72
SCREW CAB FLOOR COVERING M 6X25
81
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
81
NUT , Replaced By: N910113006001
99
PUMP WITH RESERVOIR
99
PUMP WITH RESERVOIR "DELIMON"
110
LINE GAS LINE 10X1,5, LENGTH AVAILABLE 3000 MM REPAIR WORK SUBJECT TO SAFETY CHECK
112
NUT. UNION NUT LINE CONNECTION
114
CUTTING RING. GLAND LINE CONNECTION
116
BULKHEAD FITTING DELIVERY LINE TO FRAME
118
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
120
CONNECTOR HOSE LINE & PRESSURE GAUGE TO BRACKET,067094
122
OIL PRESSURE GAUGE
124
ELBOW OVERFLOW LINE
180
HOSE FROM PUMP TO DISTRIBUTOR AT FRONT AXLE, FROM IDENT NO. 068717 ALSO INSTALLED ON 068708,068814,068718,068731 EXCEPT FOR 068424,068462. ORDER BY THE METER
189
THREADED CHUCK FOR HOSE
198
FITTING FOR HOSE
201
ELBOW REFILLING CONNECTION,083947
216
CONNECTOR REFILLING CONNECTION
220
CONNECTOR REFILLING CONNECTION
225
BRACKET REFILLING CONNECTION
234
SCREW BRACKET TO CROSS CONNECTION STRUT
234
SCREW CAB FLOOR COVERING M 6X25
234
SCREW , Replaced By: N304017008034
243
WASHER , Replaced By: N000125008443
243
WASHER EXHAUST MUFFLER TO STRAP
243
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
252
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
252
NUT BRACKET TO SIDE MEMBER
252
NUT , Replaced By: N913004006001
252
NUT PUMP TO BRACKET
261
GREASE NIPPLE PROTECTIVE TUBE
261
GREASE NIPPLE
261
GREASE NIPPLE
270
FITTING PLASTIC PIPE TO CONTROL SHUT-OFF LEVER
279
SEAL CONE PLASTIC PIPE TO SLACK ADJUSTER,044678
279
SEAL CONE , Replaced By: A0019909467
288
OIL PRESSURE GAUGE
291
PRESSURE GAUGE
295
BRACKET PRESSURE GAUGE
297
BRACKET PRESSURE GAUGE
306
PUMPVOGEL
315
DISTRIBUTOR FRONT AXLE,044679
315
DISTRIBUTORVOGEL
315
DISTRIBUTORVOGEL
315
DISTRIBUTOR FRONT AXLE
350
BRACKET
360
BRACKET
370
SCREW PLATE TO VALVE M 6X70
370
SCREW BRACKET TO CROSS CONNECTION STRUT
370
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
370
SCREW , Replaced By: N304017008034
370
SCREW , Replaced By: N304017008016
380
NUT BRACKET TO SIDE MEMBER
999
REPAIR KIT"DELIMON"
999
PUMP WITH RESERVOIR
999
SCREW. UNION SCREW , Replaced By: A0009973734
