Mercedes
BUS
0 302 OTOMARSAN/TUERKEI
373.083
55 SPECIAL INSTALLATIONS
001 HYDRAULIC SYSTEM IL. 1

0 302 OTOMARSAN/TUERKEI - 373.083 - 55 SPECIAL INSTALLATIONS

Поз.
Артикул
Описание
1
A0021313201
COMPRESSORTHERMO-KING
5
A0001312302
CYLINDER LINER
13
A0001311304
VALVE CYLINDER HEAD,TOP
24
A0001313480
GASKET CYLINDER CRANKCASE,FRONT
44
A0001302820
VALVE CHECK VALVE
48
A0009901032
56
A0001313580
GASKET OIL PAN
88
A0001320033
COVER
100
A0029810925
BALL BEARING CRANKSHAFT,FRONT
104
A0001313216
CRANKSHAFT
116
A0029810825
BALL BEARING CRANKSHAFT,REAR
124
A0001312350
128
A0001310433
BEARING SHELL
132
A0001301016
CONNECTING ROD
140
A0001301017
PISTON
184
A0001302920
188
A0001311107
192
A0001313608
SPRING PRESSURE VALVE
200
A0001310609
212
A0019903740
WASHER
220
A0001310034
STRAINER
240
N000912012085
SCREW COMPRESSOR TO CONSOLE M 12X55
244
N912004012100
LOCK WASHER FITTING TO BRACKET
248
A0001323708
252
A0009907712
260
A0002350196
264
A0019974547
268
A0001320045
FLANGE ,017983
272
A0009905721
276
A0009901246
280
A0001320073
284
A0001320215
288
A0005863913
REPAIR KIT CLUTCH,017983
292
A0001320173
296
A0001320060
SEAL RING ,017983
300
A0002350198
304
A0029901251
308
A0009902847
312
A0001320070
316
A0001320245
320
A0001310262
THRUST RING ,017983
324
A0001313480
GASKET CYLINDER CRANKCASE,FRONT
328
A0001320160
SEAL RING CYLINDER CRANKCASE,FRONT
336
N000127012201
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
340
N000912012205
999
A0001302620
VALVE
999
A0001302720
VALVE
999
A0001313380
GASKET
999
A0001320145
999
A0001322808
999
A0029812625
BALL BEARING DISC SUPPORT
999
A0029978192
999
A3025500040
999
A3025500133
999
A3025500238
999
A3141550228
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
999
A3521550172
NUT ALTERNATOR
999
N000007008221
CYLINDRICAL PIN ,A 057455, 341.023,027,032,034,036,038,041,042,043,044,045 FROM IDENT NO. A 057456 SEE SPARE PARTS LIST 713.0, MF 859A 077314, 341.116 FROM IDENT NO. A 077315 SEE SPARE PARTS LIST 713.0, MF 859
