Поз.
Артикул
Описание
6
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
6
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
6
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
6
HOSE , Replaced By: A0009872827
10
UNION NUT , Replaced By: N915017012100
10
UNION NUT LINE CONNECTION, Replaced By: N000000006239
10
UNION NUT LINE CONNECTION
14
GLAND , Replaced By: A0019901967
14
SEAL CONE LINE CONNECTION
17
SLEEVE LINE CONNECTION
17
BUSHING , Replaced By: N915062009000
20
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
20
BANJO UNION , Replaced By: N915052009009
25
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
28
UNION NUT LINE CONNECTION
28
UNION NUT , Replaced By: N915017008100
31
GLAND LINE CONNECTION
34
SLEEVE LINE CONNECTION
34
SLEEVE , Replaced By: N915062006000
37
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
37
BANJO UNION
40
LOOM TIE LINE MOUNTING
43
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
43
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
43
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
46
FITTING DELIVERY LINE TO PUMP
50
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
50
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
50
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
50
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
55
ELBOW FITTING DELIVERY LINE TO PUMP
55
ELBOW FITTING DELIVERY LINE TO PUMP
55
ELBOW FITTING DELIVERY LINE TO PUMP
55
ELBOW FITTING DELIVERY LINE TO PUMP
60
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
63
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
68
T-FITTING
68
T-FITTING
68
T-FITTING
71
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
71
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
73
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
73
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
75
NUT STRAP TO BRACKET
75
NUT , Replaced By: N910113010000
80
BRACKET TRAILER CONTROL VALVE
80
BRACKET TRAILER CONTROL VALVE
80
BRACKET TRAILER CONTROL VALVE
83
BRACKET TRAILER CONTROL VALVE,4 637964
83
BRACKET TRAILER CONTROL VALVE
86
SCREW CONSOLE TO SIDE MEMBER
86
SCREW CONSOLE TO SIDE MEMBER
86
SCREW CONSOLE TO SIDE MEMBER
86
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
86
SCREW , Replaced By: N308676012026
89
WASHER LEFT AND RIGHT CONSOLES TO CAB
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
95
SCREW , Replaced By: N308676012026
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
95
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
95
SCREW CONSOLE TO SIDE MEMBER
100
WASHER
100
WASHER
100
WASHER
100
WASHER
103
WASHER LEFT AND RIGHT CONSOLES TO CAB
105
NUT SUPPORT TO SIDE MEMBER
105
NUT SUPPORT TO SIDE MEMBER
110
NUT CHECK VALVE TO AIR RESERVOIR
113
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
113
THRUST RING CHECK VALVE TO AIR RESERVOIR
116
O-RING CHECK VALVE TO AIR RESERVOIR
120
ELBOW FITTING , Replaced By: A0004294638
120
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
120
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
130
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
133
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
136
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
136
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
138
NUT CHECK VALVE TO AIR RESERVOIR
138
NUT CHECK VALVE TO AIR RESERVOIR
141
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
141
THRUST RING CHECK VALVE TO AIR RESERVOIR
144
O-RING CHECK VALVE TO AIR RESERVOIR
147
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
147
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
150
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
150
VALVE TWO-WAY VOSS
151
VALVE BODYTO 002 429 95 44
152
BALLTO 003 429 22 44
153
GASKETTO 003 429 22 44
154
T-FITTING RELAY VALVE,CONNECTION: "12"
154
T-FITTING RELAY VALVE,CONNECTION: "12"
154
T-FITTING RELAY VALVE,CONNECTION: "12"
154
T-FITTING RELAY VALVE,CONNECTION: "12"
156
TEST CONNECTION
156
TEST CONNECTION
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
156
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
PLUG
160
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
160
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
164
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
168
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
171
NUT CHECK VALVE TO AIR RESERVOIR
171
NUT CHECK VALVE TO AIR RESERVOIR
175
THRUST RING CHECK VALVE TO AIR RESERVOIR
175
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
178
O-RING CHECK VALVE TO AIR RESERVOIR
182
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
185
SEAL RING LINE CONNECTION
188
O-RING CHECK VALVE TO AIR RESERVOIR
191
T-FITTING TWO-WAY VALVE,CONNECTION "1.2"
191
T-FITTING TWO-WAY VALVE,CONNECTION "1.2"
195
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
195
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
198
THRUST RING CHECK VALVE TO AIR RESERVOIR
198
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
198
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
198
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
204
TEST CONNECTION
208
PLUG
209
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
209
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
210
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
214
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
214
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
214
SEAL RINGTO 006 997 00 72
220
NUT CHECK VALVE TO AIR RESERVOIR
223
THRUST RING CHECK VALVE TO AIR RESERVOIR
223
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
226
O-RING CHECK VALVE TO AIR RESERVOIR
235
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
235
FITTING ,4 667210
238
WASHER BRAKE LINE MOUNTING
241
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
VALVE , Replaced By: A0004290782
999
VALVE , Replaced By: A0004291182
