Поз.
Артикул
Описание
300
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 1303 MM-KRUPP
315
DRIVE FLANGE
318
UNIVERSAL JOINT CROSS WITH BUSHINGS
318
UNIVERSAL JOINT CROSS WITH BUSHINGS
321
GREASE NIPPLE
321
GREASE NIPPLE
324
SNAP RING AS REQUIRED 3.00 MM
324
SNAP RING AS REQUIRED 2.95 MM
324
SNAP RING AS REQUIRED 2.90 MM
324
SNAP RING AS REQUIRED 2.85 MM
324
SNAP RING AS REQUIRED 2.80 MM
330
GREASE NIPPLE PROTECTIVE TUBE
336
PROTECTIVE CAP
339
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
339
SCREW , Replaced By: N308676012013
339
SCREW , Replaced By: A0079901001
339
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
342
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
342
LOCK WASHER , Replaced By: N912004010102
345
NUT BRAKE ANCHOR PLATE TO REAR AXLE M 12X1.5
345
NUT , Replaced By: N308673010001
500
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1444 MM
515
DRIVE FLANGE
518
UNIVERSAL JOINT CROSS WITH BUSHINGS
521
GREASE NIPPLE
521
GREASE NIPPLE
524
LOCK1.825 MM
524
LOCK1.800 MM
524
LOCK1.775 MM
524
LOCK1.750 MM
524
LOCK1.725 MM
524
LOCK1.700 MM
550
UNIVERSAL JOINT
568
GREASE NIPPLE
571
GREASE NIPPLE
571
GREASE NIPPLE
574
LOCK1.825 MM
574
LOCK1.800 MM
574
LOCK1.775 MM
574
LOCK1.750 MM
574
LOCK1.725 MM
574
LOCK1.700 MM
579
BOOT
580
CLAMPING RING BOOT TO PROPELLER SHAFT
582
LOOM TIE
582
CLAMP. LOOM TIE90-110
582
LOOM TIE. CLAMP
589
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
592
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
595
NUT BRAKE ANCHOR PLATE TO REAR AXLE M 12X1.5
