Поз.
Артикул
Описание
270
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE,5 007175
272
REPAIR KIT
276
T-FITTING TWO-WAY VALVE,CONNECTION "1.2"
280
ELBOW FITTING , Replaced By: A0019904371
280
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
282
FITTING BRAKE PRESSURE REGULATOR CONNECTION, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
284
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
286
NUT CHECK VALVE TO AIR RESERVOIR
288
O-RING CHECK VALVE TO AIR RESERVOIR
290
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
296
SEAL RING LINE CONNECTION
297
SCREW , Replaced By: N304017008018
297
SCREW SUPPORT TO FENDER
298
NUT , Replaced By: N913004008001
298
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
STRAINERTO 000 434 21 01
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION CONNECTION: 4.2,4 719029
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
PROTECTIVE CAP
999
CUPTO 001 431 43 05,BOSCH-TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
CUP , Replaced By: A0004340486
999
CUPTO 000 434 10 01
999
BUSHINGTO 000 434 10 01
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342101
999
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
REPAIR KIT SLAVE CYLINDER TO 000 296 01 07
999
REPAIR KIT , Replaced By: A0004305860
999
SLEEVE , Replaced By: N915062006000
999
T-FITTING 3/2-WAY VALVE
999
HOLLOW SCREW , Replaced By: N915047008100
999
BANJO UNION , Replaced By: N915052004006
999
T-FITTING RELAY VALVE,CONNECTION: "20"
999
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
999
ELBOW FITTING COMPRESSED AIR LINE THRU FRAME, Replaced By: N000000006195
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "23", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BUSHING , Replaced By: N915062004000
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
LOOM TIE , Replaced By: N916017011000
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FITTING , Replaced By: A0019972572
999
HANDLETO 000 434 23 01
999
PLUGTO 009 420 22 18,008 420 20 18
999
PLUG
999
VALVE , Replaced By: A0034291644
999
VALVE , Replaced By: A0044293144
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 281211, Replaced By: A0024294344
999
VALVE (RELAY VALVE) GRAU
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 90 18, BOSCH
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
CUPTO 002 431 04 06,BOSCH
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
VALVE , Replaced By: A0014315806
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
SEAL RING 34X2,3 MM TO 001 431 68 06 34X2.3 MM,TO 001 431 68 06,GRAU
999
SEAL RING , Replaced By: A0009971548
999
GASKET , Replaced By: A0004311980
999
VALVE FOUR-CIRCUIT PROTECTIVE VALVE KNORR, MODELS 002,003,006,007,009,034,UP TO CHASSIS 4 424733,MODELS 134 UP TO CHASSIS 4 611513
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
VALVE , Replaced By: A0014318406
999
VALVE , Replaced By: A0024312806
999
BRAKE VALVE TWO-CIRCUIT BRAKE VALVE BOSCH-TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPRINGTO 000 434 21 01
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) BOSCH
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
BRAKE VALVE TWO-CIRCUIT BRAKE VALVE WABCO-SCHAEFER, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 001 429 52 44
999
REPAIR KITBOSCH
999
REPAIR KITTO 001 429 20 44,BOSCH
999
REPAIR KIT SPRING LOAD ACCUMULATOR CYLINDER TO 006 420 05 18, FROM AXLE 213195,UP TO AXLE 213194 SEE SPARE PARTS LIST 740.104
999
REPAIR KIT DIAPHRAGM CYLINDER TO 006 420 05 18, FROM AXLE 213195,UP TO AXLE 213194 SEE SPARE PARTS LIST 740.104
999
REPAIR KIT TO 001 431 35 06 TO 001 431 35 06,KNORR
999
REPAIR KIT , Replaced By: A0034300781
999
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 427
999
REPAIR KIT , Replaced By: A0004301407
999
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 428
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING AIR RESERVOIR,CONNECTION: "13", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
T-FITTING POWER STEERING
999
ELBOW FITTING SHUTTLE VALVE TO BRAKE CYLINDER
999
SEAL CONE LINE CONNECTION
999
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
999
T-FITTING EXHAUST BRAKE LINE CONNECTION
999
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
999
FITTING LINE CONNECTION, Replaced By: N000000006446
999
PLUGTO 008 420 59 18,KNORR
999
FITTING , Replaced By: N915059004000
999
FITTING , Replaced By: N915059006000
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
REPAIR KIT DIAPHRAGM PART TO 006 420 56 18,4 326657
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
VALVE , Replaced By: A0044293144
999
VALVE , Replaced By: A0034295344
999
VALVE ,4 281211, Replaced By: A0024294844
999
VALVE (CHECK VALVE),4 281211
999
VALVE , Replaced By: A0044293244
999
VALVE
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
BRAKE VALVE TWO-CIRCUIT BRAKE VALVE BOSCH-SCHAEFER, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE FOUR-CIRCUIT PROTECTIVE VALVE BOSCH, MODELS 002,006 UP TO CHASSIS 4 424733,MODELS 033,034,134 UP TO CHASSIS 4 611513 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , Replaced By: A0024319206
999
VALVE , Replaced By: A0024319306
999
PRESSURE REGULATOR , Replaced By: A0024314306
999
VALVE FOUR-CIRCUIT PROTECTIVE VALVE GRAU, MODELS 002,003,006,007,009,034,UP TO CHASSIS 4 424733,MODELS 134 UP TO CHASSIS 4 611513
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) GRAU, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT , Replaced By: A0025865242
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
REPAIR KIT VALVE DISC TO 001 431 43 05,002 431 05 05,BOSCH, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 001 431 47 06,WABCO 2100, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITKNORR
999
REPAIR KIT BOOT TO 001 431 15 06,BOSCH
999
REPAIR KIT SEAL RING TO 001 431 15 06,BOSCH
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KITTO 001 431 30 06
999
REPAIR KITGRAU,5 148812
999
REPAIR KIT , Replaced By: A0034303881
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING LINE CONNECTION TO AIR RESERVOIR,4 314180
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
FITTING DELIVERY LINE TO PUMP
999
FITTING ,4 412020
999
FITTING AT TRISTOP CYLINDER,4 691315
999
FITTING ,4 261891
999
FITTING DISTRIBUTOR,4 709826
999
VALVE (RELAY VALVE) BOSCH
999
VALVE (RELAY VALVE) KNORR
999
REPAIR KIT
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
GASKET KIT SEAL RING TO 001 431 58 06,BOSCH
999
WHEEL BRAKE CYLINDER ,4 326656, Replaced By: A0064200418, +002N913004016004
999
WHEEL BRAKE CYLINDER ,4 356393, Replaced By: A0064201018, +002N913004016004
999
VALVE (OVERFLOW VALVE) WABCO
999
VALVE (OVERFLOW VALVE) GRAU
999
SEAL RINGBOSCH
999
FITTING , Replaced By: A0029906171
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
HOSE CLAMP LINE MOUNTING
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING 25.3X2.4 MM,TO 001 431 68 06, 002 431 02 06
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RINGTO 000 434 21 01
999
WHEEL BRAKE CYLINDER ,4 326657 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 404254, Replaced By: A0064701118
999
WHEEL BRAKE CYLINDER , Replaced By: A0064201018
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
WHEEL BRAKE CYLINDER SLAVE CYLINDER SCHAEFER,TO001 431 94 05,002 431 05 05, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER KNORR
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 001 431 68 06,19.3X2.4 MM,GRAU37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
SEAL RINGTO 001 431 43 05
999
SEAL RING , Replaced By: A0049970248
999
SEAL RING BRAKE HOSE
999
VALVE CLUTCH SLAVE CYLINDER
999
CLAMP 3/2-WAY SOLENOID VALVE
999
PROTECTIVE CAP , Replaced By: A0004210887
999
BRACKET , Replaced By: A3604293140
999
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
999
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
999
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP LINE MOUNTING
999
GROMMET ,5 585846
999
BRACKET ,4 375135
999
BRACKET ,4 270413
999
LINE , Replaced By: A3874299502, +001N003861012006, +001N003870012104
999
LINE , Replaced By: A3874299502, +001N003861012006, +001N003870012104
999
LINE , Replaced By: A0004291401
999
BRAKE ANCHOR TRISTOP CYLINDER
999
BRACKET PRESSURE GAUGE LINE TO BRACKET,4 895864
999
BRACKET LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
LINE , Replaced By: A3874299502
999
STRAP , 974676 MODELS 002,006 UP TO CHASSIS 4 424733,MODELS 033,034,134 UP TO CHASSIS 4 611513
999
SHIM APPARATUS SUPPORT TO FRAME SIDE MEMBER
