Поз.
Артикул
Описание
5
FRONT SPRING 10-LEAF
5
FRONT SPRING 10-LEAF
8
SPRING LEAFNO.1TO 397 320 00 02
8
SPRING LEAFNO.1
11
BUSHING
11
BUSHING
14
SPRING LEAFNO.2 TO 397 320 00 02
14
SPRING LEAFNO.2
17
SPRING LEAFNO.3 TO 397 320 00 02
17
SPRING LEAF WITH SPRING CLAMP NO.3
20
SPRING CLAMP , Replaced By: A6173210333
20
SPRING CLAMP , Replaced By: A6173210333
23
RIVET SPRING CLAMP TO SPRING LEAF
26
SPACER TUBE SPRING CLAMP
29
SCREW SPRING CLAMP,5 533057
32
NUT BRACKET TO LEFT SIDE MEMBER
35
SPRING LEAFNO.4 TO 397 320 00 02
38
SHACKLE AT SPRING LEAF NO.4 TO 397 321 01 14
41
PROTECTIVE TUBE AT SPRING LEAF NO.8 TO 397 321 01 18
44
WASHER
47
SCREW AT SPRING LEAF NO.11 TO 397 321 00 21
47
SCREW SPRING CLAMP
50
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
53
SPACER TUBE SPRING CLAMP
56
SPACER TUBE AT SPRING LEAF NO.8 TO 397 321 01 18
59
SPRING LEAFNO.5 TO 397 320 00 02
62
SPRING CLAMP , Replaced By: A6173210333
62
SPRING CLAMP , Replaced By: A6173210333
65
RIVET SPRING CLAMP TO SPRING LEAF
68
SPACER TUBE SPRING CLAMP
71
SCREW SPRING CLAMP,5 533057
74
NUT BRACKET TO LEFT SIDE MEMBER
77
SPRING LEAFNO 8 TO 397 320 00 02
80
SHACKLE AT SPRING LEAF NO.8 TO 397 321 01 18
83
SPACER TUBE SPRING CLAMP
86
SPACER TUBE AT SPRING LEAF NO.8 TO 397 321 01 18
89
PROTECTIVE TUBE AT SPRING LEAF NO.8 TO 397 321 01 18
92
WASHER
95
SCREW AT SPRING LEAF NO.11 TO 397 321 00 21
95
SCREW SPRING CLAMP
98
NUT STRAP TO SUPPORT
98
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
101
SPRING BOLTM 12X165
104
NUT BRACKET TO BEARING BRACKET
104
NUT BRACKET TO SIDE MEMBER
107
SHACKLE FRONT SPRING TO SPRING BRACKET
107
SHACKLE , USED WITH AIR BRAKE,UP TO CHASSIS 588185
110
BUSHING
110
BUSHING
113
SHACKLE PIN (PARTS KIT) FRONT SPRING TO FRONT SPRING BRACKET
113
REPAIR KIT , Replaced By: A3853200065
116
GREASE NIPPLE
119
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
119
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
122
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
125
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
128
WASHER , Replaced By: N000125010532
131
NUT EXHAUST PIPE TO SIDE MEMBER
131
NUT , Replaced By: N910113010000
134
PLATE FRONT SPRINGS TO FRONT AXLE
137
HELPER SPRING ,6951998 0000014 168249, Replaced By: A3183240008, +001A3143310727, +001A3143310827
140
U-BOLT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 321 351 07 25
140
U-BOLT FRONT SPRINGS TO FRONT AXLE 210 MM
143
NUT
146
SHIM FRONT AXLE,RIGHT
