Поз.
Артикул
Описание
5
VALVE 3/2-WAY WABCO
5
VALVE 3/2-WAY BOSCH
5
VALVE 3/2-WAY KNORR
5
VALVE 3/2-WAY WABCO
5
VALVE 3/2-WAY VOSS
13
SPRING INSIDE WABCO
21
SEAL RING INSIDE WABCO
29
SEAL RING TOP WABCO
37
FITTING , NOT USED
45
SEAL RING , Replaced By: N007603010110
45
SEAL RING , Replaced By: N007603010110
53
WASHER 3/2-WAY VALVE TO BRACKET
61
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
69
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
77
SCREW-IN FITTING SERVICE BRAKE VALVE
77
FITTING DELIVERY LINE TO PUMP
77
FITTING DELIVERY LINE TO PUMP
85
NUT CHECK VALVE TO AIR RESERVOIR
93
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
93
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
93
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
101
SEAL RING QUICK-RELEASE VALVE,CONNECTIONS: "1,2"
109
VALVE , Replaced By: A0024311206
109
VALVE (PRESSURE RELIEF VALVE)
119
REPAIR KIT , Replaced By: A0004200871
119
REPAIR KIT PRESSURE RELIEF VALVE
125
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
133
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
133
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
141
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
141
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
149
VALVE (QUICK-RELEASE VALVE)
157
SEAL RING , Replaced By: A0159970448
157
SEAL RINGWABCO
165
DIAPHRAGMWABCO
173
FITTING , Replaced By: A0009970171
181
NUT CHECK VALVE TO AIR RESERVOIR
189
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
189
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
197
O-RING CHECK VALVE TO AIR RESERVOIR
205
SCREW PLUG , Replaced By: N000908022011
213
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
213
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
213
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
221
UNION NUT LINE CONNECTION
229
GLAND LINE CONNECTION
237
LINE12 MM, ORDER BY THE METER4 691315
237
LINE12 MM, ORDER BY THE METER4 691315
237
LINE12 MM, ORDER BY THE METER4 691315
237
LINE12 MM, ORDER BY THE METER4 691315
245
UNION NUT LINE CONNECTION, Replaced By: N000000006239
253
GLAND , Replaced By: A0019901967
261
FITTING LINE CONNECTIONS,4 412125
269
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
277
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
285
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
CLAMP ,K 147121, Replaced By: N000000000319
999
FITTING
999
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
999
BANJO UNION HEATING CONNECTION,K 169122
999
HOLLOW SCREW HAND BRAKE VALVE,CONNECTION: "20"
999
NUT , Replaced By: N913004008001
999
SEAL RING FUEL LINE TO FEED PUMP
999
CONNECTION FITTING ,880809
999
SCREW , Replaced By: N304017008021
999
UNIT IDENTIFICATION PLATE 3/2-WAY VALVE TO CAB
999
BRACKET QUICK-RELEASE VALVE
999
CLAMP , Replaced By: A3604300143
999
CLAMP , Replaced By: N916016008200
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
FITTING , Replaced By: A0029905971
999
VALVE TWO-WAY
999
FITTING (PARTS KIT),LINE RUPTURE
999
VALVE TWO-WAY
999
LOOM TIE LINE MOUNTING 280 MM
999
FITTING , Replaced By: N915059006000
