Поз.
Артикул
Описание
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "KNORR"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "BOSCH"
5
VALVE PARKING BRAKE WITH TRAILER CONTROL "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HANDLETO 002 430 93 81
11
BUSHING"WABCO"
11
BUSHING , Replaced By: A4421440050
14
BUSHINGTO 002 430 93 81
17
PROTECTIVE CAPTO 002 430 93 81
20
LEVERTO 002 430 93 81
23
SPRING RETAINERTO 002 430 93 81
26
PINTO 002 430 90 81
29
PINTO 002 430 93 81
32
REPAIR KITBOSCH,TO 002 430 93 81
32
REPAIR KIT HAND BRAKE VALVE "WABCO"
35
SCREW PARKING BRAKE VALVE TO WINDOW SILL
38
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
38
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL, Replaced By: N912006008000
41
GUMMED LABEL PARKING BRAKE ACTUATION
44
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30"
44
BREATHER PIPE PARKING BRAKE VALVE,CONNECTION: "30", Replaced By: A6554310273
47
SCREW. UNION SCREW LINE CONNECTION
47
SCREW. UNION SCREW , Replaced By: A0009973734
48
CLAMP HOSE TO PARKING BRAKE VALVE
50
TRAILER CONTROL VALVE (TRAILER CONTROL VALVE) "KNORR"
50
BRAKE VALVE (TRAILER CONTROL VALVE) "GRAU", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
50
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
50
BRAKE VALVE (TRAILER CONTROL VALVE) "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
53
REPAIR KIT TRAILER CONTROL VALVE "GRAU"
53
REPAIR KIT TRAILER CONTROL VALVE "WABCO"
56
BRACKET TRAILER CONTROL VALVE
59
SCREW BRACKET TO CROSS CONNECTION STRUT
59
SCREW , Replaced By: N304017008034
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
NUT , Replaced By: N913004008001
65
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
68
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW LINE CONNECTION
71
SCREW. UNION SCREW , Replaced By: A0009973734
74
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
77
ANGLE SUPPORT,RIGHT
77
ANGLE SUPPORT,LEFT
80
SCREW PIPE CLAMP
80
SCREW , Replaced By: N304017008021
80
SCREW BRACKET TO CROSS CONNECTION STRUT
80
SCREW , Replaced By: N304017008034
83
WASHER EXHAUST MUFFLER TO STRAP
83
WASHER , Replaced By: N000125008443
86
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
86
NUT , Replaced By: N913004008001
89
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
89
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
89
SCREW , Replaced By: N308676014020
92
NUT BRACKET TO SIDE MEMBER
92
NUT , Replaced By: N910113014001
95
ADAPTER FITTING LINE CONNECTION TO ENGINE
95
ADAPTER FITTING LINE CONNECTION TO ENGINE
96
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
97
ELBOW FITTING CONNECTION OF COMPRESSED AIR LINE 9 MM, M 18X1.5,K 168170
98
NUT BRACKET TO SIDE MEMBER
101
SCREW. UNION SCREW LINE CONNECTION
