Поз.
Артикул
Описание
5
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
11
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
14
CONNECTOR DISTRIBUTOR TO CAB
14
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
17
SEAL RING
17
SEAL RING , Replaced By: A0229973948
17
SEAL RING CONNECTOR 11.8X2 MM
20
ELBOW FITTING , Replaced By: A0049905371
20
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
23
SEAL RING , Replaced By: A0009940747
23
LOCK RING LINE CONNECTION
23
LOCK RING LINE CONNECTION
26
LOCK , Replaced By: A0009945448
26
LOCK LINE CONNECTION
26
LOCK LINE CONNECTION
29
REPAIR KIT , Replaced By: A0309971748
29
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
29
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
32
VALVE (3/2-WAY SOLENOID VALVE) EKS
35
PROTECTIVE CAPWABCO
38
SEAL RINGWABCO
38
SEAL RINGBOSCH
38
SEAL RINGBOSCH
40
GASKET KITKNORR
41
SCREW , Replaced By: N304017008043
41
SCREW VALVE TO BRACKET M 8X55
44
NUT , Replaced By: N913004008001
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
47
BRACKET 3/2-WAY SOLENOID VALVE
47
BRACKET 3/2-WAY SOLENOID VALVE
48
BRACKET 3/2-WAY SOLENOID VALVE
49
SCREW , Replaced By: N304017008034
49
SCREW BRACKET TO CROSS CONNECTION STRUT
50
NUT , Replaced By: N913004008001
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
51
HOLLOW SCREW HEATING CONNECTION
53
SEAL RING LINE CONNECTION
56
VALVE (PRESSURE RELIEF VALVE)
59
REPAIR KIT REDUCTION VALVE
59
REPAIR KIT REDUCTION VALVE
62
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
65
SEAL RING LINE CONNECTION
68
FITTING , Replaced By: A0009977172
68
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
71
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
71
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
74
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
77
SEAL RING LINE CONNECTION
80
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
83
SHUTTLE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0044292444
83
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
86
SCREW. UNION SCREW , Replaced By: A0009973734
86
SCREW. UNION SCREW LINE CONNECTION
87
ELBOW FITTING RELAY VALVE,CONNECTION: "20"
89
FITTING RELAY VALVE,CONNECTION: "40"
92
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
98
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
CONNECTOR HOSE WIDTH, 6 MM,TO M16
999
CONNECTOR , Replaced By: A0029905478
