Поз.
Артикул
Описание
26
LOCK RING LINE CONNECTION
26
SEAL RING , Replaced By: A0009940747
29
LOCK LINE CONNECTION
29
LOCK , Replaced By: A0009945448
32
REPAIR KIT , Replaced By: A0309971748
32
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
71
BRACKET COMPRESSED AIR LINE TO INTAKE MANIFOLD, LEFT FRONT
72
BRACKET (T-FITTING) EXHAUST BRAKE LINE CONNECTION,5 908244K 012508
74
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
75
T-FITTING LINE CONNECTION
76
HOLLOW SCREW LINE CONNECTION
77
SEAL RING LINE CONNECTION
78
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
79
SCREW BRACKET TO ENGINE
80
WASHER
80
WASHER , Replaced By: N007349008007
81
ANGLE LINE MOUNTING
83
CLAMP LINE MOUNTING
83
CLAMP LINE MOUNTING
84
SCREW PUMP TO BRACKET
84
SCREW , Replaced By: N304017006016
85
NUT , Replaced By: N913002006009
85
NUT OIL TANK TO BRACKET
90
LOOM TIE BRAKE LINE MOUNTING
92
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL WABCO
92
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL BOSCH
93
REPAIR KIT 3/2-WAY VALVE WABCO
93
REPAIR KIT 3/2-WAY VALVE BOSCH
94
SPRING WASHER AT CAB FLOOR
95
NUT SUCTION LINE TO OIL PUMP
96
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
96
BREATHER , Replaced By: A3933280065
97
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
97
SCREW PLUG , Replaced By: N000908012009
99
SEAL RING LINE CONNECTION
101
SCREW. UNION SCREW LINE CONNECTION
101
SCREW. UNION SCREW , Replaced By: A0009973734
104
VALVE , Replaced By: A0049975736
104
VALVE (3/2-WAY SOLENOID VALVE) EKS
105
PROTECTIVE CAPWABCO
107
SEAL RINGBOSCH
107
SEAL RINGWABCO
109
SEAL RINGBOSCH
110
GASKET KITKNORR
111
SCREW VALVE TO BRACKET
111
SCREW VALVE TO BRACKET, Replaced By: N304014008002
113
NUT , Replaced By: N913004008001
113
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
113
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
116
BRACKET 3/2-WAY SOLENOID VALVE
119
BRACKET 3/2-WAY SOLENOID VALVE
122
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
122
SCREW , Replaced By: N304017008016
125
WASHER , Replaced By: N000125008443
125
WASHER EXHAUST MUFFLER TO STRAP
128
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
131
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
131
NUT , Replaced By: N913004008001
131
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
134
HOLLOW SCREW HEATING CONNECTION
137
SEAL RING LINE CONNECTION
140
SCREW TO PLUG THE FREE CONNECTIONS
143
SEAL RINGBOSCH
146
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
149
SCREW OIL TANK TO BRACKET
152
NUT PUMP TO BRACKET
152
NUT , Replaced By: N913004006001
158
BRACKET , Replaced By: A6504312840
158
BRACKET , Replaced By: A6554316740
158
BRACKET CONNECTOR TO FRAME
161
SCREW TWO-WAY VALVE TO BRACKET
164
NUT TWO-WAY VALVE TO BRACKET
167
HOLLOW SCREW FUEL LINE TO FEED PUMP
167
HOLLOW SCREW , Replaced By: N915036010108
170
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
173
SEAL RING FUEL LINE TO FEED PUMP
176
VALVE (3/2-WAY SOLENOID VALVE) WABCO
177
SEAL RINGWABCO
178
VALVE PARTWABCO
179
SEAL RINGWABCO
180
SEAL RINGWABCO
181
SCREW VALVE TO BRACKET M 8X55
181
SCREW , Replaced By: N304017008043
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
NUT , Replaced By: N913004008001
182
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
185
BRACKET 3/2-WAY SOLENOID VALVE
188
SCREW END PIECE TO EXHAUST PIPE M 12X30
188
SCREW , Replaced By: N304017012020
191
NUT END PIECE TO EXHAUST PIPE
194
HOLLOW SCREW HEATING CONNECTION
197
SEAL RING LINE CONNECTION
200
FITTING CONNECTION TO STOP LIGHT SWITCH
200
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
203
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
203
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
206
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
