Поз.
Артикул
Описание
8
PUMP (HAND PUMP) POWER PACKER
8
PUMP (HAND PUMP) WEBER
11
PISTONTO 000 553 79 01,WEBER
14
VALVETO 000 553 79 01,WEBER
17
FILTERHUNGER
17
FILTER
23
FITTED WASHER
26
LOCK RING
29
SCREW OIL FILLING HUNGER
29
SCREW
35
SCREW BOX COVER TO 000 553 79 01,000 553 89 01
35
SCREW , Replaced By: N000912008201
35
SCREW
35
SCREW , Replaced By: N000000000190
38
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
40
GASKETHUNGER
47
GASKET KIT HAND PUMP TO 000 553 68 01
47
GASKET KIT HAND PUMP
48
BRACKET HAND PUMP
49
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
49
SCREW , Replaced By: N308676014020
49
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
50
SCREW END PIECE TO EXHAUST PIPE M 10X25
50
SCREW BRACKET TO SIDE MEMBER
52
NUT BRACKET TO SIDE MEMBER
52
NUT , Replaced By: N910113014001
54
NUT STRAP TO BRACKET
54
NUT STRAP TO BRACKET
54
NUT , Replaced By: N910113010000
110
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACK
110
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING WEBER
111
GUIDEWEBER,TO 001 553 45 05
111
GUIDEWEBER
113
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
113
GASKET KIT HYDRAULIC CYLINDER HUNGER,TO 000 553 89 05
113
GASKET KIT HYDRAULIC CYLINDER HUNGER,TO 001 553 47 05
113
GASKET KIT HYDRAULIC CYLINDER WEBER
125
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
128
WASHER HYDRAULIC CYLINDER TO CAB
131
COTTER PIN6,3X36 MM
134
WASHER HYDRAULIC CYLINDER TO CAB
137
WASHER HYDRAULIC CYLINDER TO CAB
140
WASHER HYDRAULIC CYLINDER TO CAB
143
NUT COMBINATION CYLINDER TO BEARING BRACKET
143
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
