Поз.
Артикул
Описание
17
BATTERY SUPPORT
26
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
26
SCREW EXHAUST PIPE TO BRACKET
35
CONICAL SPRING WASHER BATTERY SUPPORT TO FRAME
36
ADJUSTING WASHER SPARE WHEEL HOIST TO FRAME
37
WASHER BRACKET TO FRAME
41
NUT SUPPORT TO SIDE MEMBER
44
ANGLE BATTERY MOUNTING, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
53
BRACKET BATTERY MOUNTING,5 515832
56
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
62
CLAMPING SCREW BATTERY MOUNTING,5 419107
71
WASHER BATTERY MOUNTING, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
74
FASTENER
77
COVER
999
NUT EXHAUST PIPE TO SIDE MEMBER
999
SCREW STRUT TO FRAME, LEFT
999
SPACER TUBE ELECTRIC CABLE THRU FRAME, FROM IDENT NO.K 224007, EXCEPT FOR K 222189
