Поз.
Артикул
Описание
5
VALVE PARKING BRAKE WABCO
5
VALVE PARKING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
VALVE PARKING BRAKE BOSCH
5
VALVE PARKING BRAKE WABCO
8
HANDLETO WABCO
8
HANDLE , Replaced By: A0009972877
8
HANDLE , Replaced By: A0009972477
11
PROTECTIVE CAPTO BOSCH
11
PROTECTIVE CAPTO WABCO
14
REPAIR KITTO WABCO
14
REPAIR KIT , Replaced By: A0034303181
14
REPAIR KIT , Replaced By: A0004305206
14
BRAKE VALVE REPAIR KIT BOSCH,TO 001 430 37 81/46 81, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
14
REPAIR KITBOSCH,12 MM,001 430 37 81/46 81, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
17
SCREW , Replaced By: N304017008039
17
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
20
WASHER EXHAUST MUFFLER TO STRAP
20
WASHER , Replaced By: N000125008443
23
SCREW. UNION SCREW , Replaced By: A0009973734
23
SCREW. UNION SCREW LINE CONNECTION
26
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
26
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
26
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
29
REPAIR KIT , Replaced By: A0004304606
29
REPAIR KITTO 001 431 48 05,4 375193
29
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
29
REPAIR KITTO 001 431 37 05,4 375193
32
BRACKET TRAILER CONTROL VALVE
32
BRACKET TRAILER CONTROL VALVE, NOT USED
35
SCREW BRACKET TO SIDE MEMBER
38
NUT STRAP TO BRACKET
38
NUT , Replaced By: N910113010000
44
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
44
FITTING LINE CONNECTION
47
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
50
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
53
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
53
VALVE , Replaced By: A0044291544
56
BRACKET LOCKING VALVE, NOT USED
59
SCREW BRACKET TO CROSS CONNECTION STRUT
59
SCREW , Replaced By: N304017008034
62
SCREW , Replaced By: N304017008027
62
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
65
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
65
NUT , Replaced By: N913004008001
68
SCREW. UNION SCREW LINE CONNECTION
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
WASHER , Replaced By: N006902011102
999
WASHER , Replaced By: N006902011100
