Поз.
Артикул
Описание
5
5
8
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
9
WOODRUFF KEY
11
KNOB GEARSHIFT LEVER UPPER PART, NO.8650I.......I I I II .......INO.9985I I I II I
12
KNOB (SHIFT LEVER HANDLE), NO.8650I.......I I I II .......INO.9985I I I II I
14
VALVE (SHIFT LEVER VALVE)
14
VALVE (SHIFT LEVER VALVE) TO 388 267 71 10, DARK-BROWN NO.8650I.......I I I II .......INO.9985I I I II I
17
NUT , Replaced By: N910113010002
18
WASHER GROUND CABLE
20
COVER 1ST THRU 6TH SPEED,REVERSE SPEED
20
23
COVERING , NO.8650I.......I I I II .......INO.9985I I I II I
23
COVERING GEARSHIFT LEVER UPPER PART
26
BOOT SHIFT LEVER
26
BOOT BOTTOM
29
PLASTIC TUBE2X4MM, ORDER BY THE METER
32
UNION NUT LINE MOUNTING, Replaced By: N000000006521
35
GLAND LINE MOUNTING
38
SLEEVE LINE MOUNTING
41
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
47
UNION NUT LINE MOUNTING, Replaced By: N000000006521
47
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
50
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
53
SLEEVE LEAK LINE
68
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
74
FITTING QUICK-RELEASE VALVE
77
THRUST RING LOCKING VALVE
77
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
77
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
83
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
83
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
83
SCREW. UNION SCREW , Replaced By: A0009973734
86
SEAL RING , Replaced By: A0009940747
86
SEAL RING SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
89
LOCK , Replaced By: A0009945448
89
LOCK SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
92
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
92
LOOM TIE ELECTRIC CABLE MOUNTING
95
INSULATING HOSE COLOR CODE YELLOW, ORDER BY THE METER
95
INSULATING HOSE BLUE
95
INSULATING HOSE8X0,01 MM
95
INSULATING HOSE COLOR CODE BLUE 2X0,01 MM
98
COMBINATION BOLT TRANSMISSION TO ENGINE M10X45
98
SCREW-AND-WASHER ASSEMBLY TRANSMISSION TO ENGINEM10X45
98
SCREW TRANSMISSION TO ENGINE M 10X50
