Поз.
Артикул
Описание
5
PRESSURE REGULATORBOSCH,241, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PRESSURE REGULATORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313606
5
PRESSURE REGULATORKNORR
5
PRESSURE REGULATORWABCO
5
PRESSURE REGULATORWABCO, Replaced By: A0034313806
8
REPAIR KIT PRESSURE REGULATOR KNORR
8
REPAIR KIT PRESSURE REGULATOR BOSCH,241
8
REPAIR KIT SEAL RING BOSCH,209
8
REPAIR KIT PRESSURE REGULATOR WABCO
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
11
SCREW REAR AXLE REGULATING SOLENOID VALVE
14
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
14
NUT , Replaced By: N913004008001
17
BRACKET PRESSURE REGULATOR
20
SCREW BRACKET TO SIDE MEMBER
20
SCREW , Replaced By: N304017010002
23
NUT STRAP TO BRACKET
23
NUT , Replaced By: N910113010000
24
COVERING PRESSURE REGULATOR
26
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
32
THRUST RING CHECK VALVE TO AIR RESERVOIR
32
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
35
O-RING CHECK VALVE TO AIR RESERVOIR
41
HOLLOW SCREW HEATING CONNECTION
44
SEAL RING LINE CONNECTION
47
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
50
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
50
CLAMP , Replaced By: N000000000667
53
AIR DEHYDRATOR"KNORR",5 502947
53
AIR DEHYDRATOR"BOSCH",5 502947
53
AIR DEHYDRATOR"WABCO",5 502947
56
AIR CLEANER COMPLETE TO BOSCH,KNORR
56
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
59
SEAL RINGWABCO
62
GASKET KITKNORR
62
GASKET KITBOSCH
62
GASKET KITWABCO
65
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
65
SCREW , Replaced By: N308676012012
71
LOCK WASHER FITTING TO BRACKET
74
PROTECTIVE PLATE AIR DEHYDRATOR
80
BRACKET AIR DEHYDRATOR,5 433280
83
SCREW SUPPORT TO CROSS MEMBER M 10X28
86
NUT STRAP TO BRACKET
86
NUT , Replaced By: N910113010000
89
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
92
THRUST RING CHECK VALVE TO AIR RESERVOIR
92
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
95
O-RING CHECK VALVE TO AIR RESERVOIR
98
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
101
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
104
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
107
HOLLOW SCREW HEATING CONNECTION
110
SEAL RING LINE CONNECTION
131
MUFFLER VALVE BLEEDING
131
MUFFLER , Replaced By: A0004302070
131
MUFFLER DEHYDRATOR
143
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
143
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820, Replaced By: A0034315006
143
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
146
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
146
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE
146
REPAIR KITTO 001 431 93 06,BOSCH 62201,K 087820
146
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE
149
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
149
SCREW , Replaced By: N304017008016
152
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
164
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
167
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
173
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
179
HOLLOW SCREW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
182
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
182
THRUST RING CHECK VALVE TO AIR RESERVOIR
182
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
188
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
188
O-RING CHECK VALVE TO AIR RESERVOIR
191
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
194
SEAL RING LINE CONNECTION
197
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
200
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
203
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
203
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
