Поз.
Артикул
Описание
71
HOSE , Replaced By: A0009872827
71
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
77
UNION NUT LINE CONNECTION, Replaced By: N000000006239
77
UNION NUT LINE CONNECTION
80
GLAND , Replaced By: A0019901967
80
SEAL CONE LINE CONNECTION
83
SLEEVE LINE CONNECTION
86
FITTING (PARTS KIT),LINE RUPTURE
119
CONNECTOR
122
CONNECTOR DISTRIBUTOR TO CAB
125
CONNECTOR DISTRIBUTOR TO CAB
125
CONNECTOR DISTRIBUTOR TO CAB
128
CONNECTOR DISTRIBUTOR MIDDLE, COMPRESSED AIR LINE PLUG CONNECTION, WITH THROTTLE
131
CONNECTOR DISTRIBUTOR TO FRAME
134
CONNECTOR DISTRIBUTOR TO CAB
134
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
137
SEAL RING , Replaced By: A0229973948
137
SEAL RING CONNECTOR 11.8X2 MM
140
SEAL RING
164
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
167
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
173
SCREW EXHAUST BRAKE SEPARATION POINT
176
NUT , Replaced By: N913004006001
176
NUT PUMP TO BRACKET
179
ELBOW FITTING 3/2-WAY VALVE BREATHING
182
UNION NUT
185
GLAND , Replaced By: A0019901667
185
SEAL CONE
188
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
BRACKET BRACKET TO BRACKET
