Поз.
Артикул
Описание
5
COVERING AIR INLET AT OUTSIDE CENTRAL PART ON THE LEFT BELOW WINDSHIELD
8
COVERING AIR INLET AT OUTSIDE CENTRAL PART ON THE RIGHT BELOW WINDSHIELD
11
COVERING AIR INLET AT OUTSIDE CENTRAL PART ON THE RIGHT BELOW WINDSHIELD
14
COVERING AIR INLET AT OUTSIDE CENTRAL PART ON THE LEFT BELOW WINDSHIELD
17
RIVET COVERING TO BRACKET
20
SEAL BETWEEN CENTRAL PART BELOW WINDSHIELD AND COVERING 1604 MM
23
SEAL BETWEEN CENTRAL PART BELOW WINDSHIELD AND COVERING 240 MM
26
CLIP COVERING TO INSIDE CENTRAL PART BELOW WINDSHIELD
29
RUBBER BUFFER BRACKET AT BOX
32
PLUG TO PLUG THE BORES
35
BAFFLE WATER DRAIN,CENTER
38
SEAL BAFFLE TO CENTRAL PART BELOW WINDSHIELD
41
SEAL
44
GROMMET WATER DRAIN,AT BAFFLE
47
SHEET METAL SCREW
47
SHEET METAL SCREW BRACKET TO FIRE WALL
50
VALVE
53
HOSE WATER DRAIN,INSIDE CENTRAL PART,LEFT
56
HOSE WATER DRAIN,INSIDE CENTRAL PART,RIGHT
59
BRACKET HOSE TO WHEELHOUSE
