Поз.
Артикул
Описание
20
BACKREST FRAME
30
CLAMP TO BACKREST FRAME
40
BOLT BAR TO BACKREST FRAME M8X16
50
REST BACKREST FRAME
50
REST BACKREST FRAME
60
COVER
60
COVER , E 01277420020906 A 43949820020906 F 34460520020910 R 08212620020930 E 01938620050630805
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER , E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805 9C65 681A QFT203A2003 ANTHRACITE
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER , E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805 9C65 681A QFT203A2003 ANTHRACITE
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER
60
COVER , E 01277420020906 A 43949820020906 F 34460520020910 R 08212620020930 E 01938620050630805
70
CLIP TRANSVERSAL TACKING
70
CLIP SEAT COVER MOUNTING,TRANSVERSE
85
CLIP
100
CABLE CLAMP BOWDEN CABLE
105
BRACKET SEAT COVER MOUNTING,LONGITUDINAL
105
BRACKET SEAT COVER MOUNTING,LONGITUDINAL
106
BRACKET SEAT COVER MOUNTING,TRANSVERSE
106
CLAMP COVER STITCHING 285 MM
107
CLAMP COVER STITCHING 483.6 MM
110
BEARING TO RIGHT ARMREST, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805
110
BEARING TO LEFT ARMREST, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805
120
BEARING TO LEFT ARMREST
120
BEARING TO RIGHT ARMREST
150
BOLT ARMREST M8X8
155
SCREW BRACKET TO COVERING
158
COVER REAR BACKREST MIDDLE
160
COVER SKI-BAG
165
SCREW CONSOLE TO KNEE PROTECTION PAD
170
COVER BELT OUTLET
180
LINING BACKREST, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805 9F08QFT203A0147 SINGLE TONE BLACK
180
LINING BACKREST, 9F08QFT203A0147 SINGLE TONE BLACK
180
LINING BACKREST, Replaced By: A2039241462
190
PLUG TUNNEL
200
FLAP SKI-BAG
203
DASHPOT SKI-BAG
206
TAKE-UP DEVICE SKI-BAG
210
GUIDE REAR SEAT HEADREST CENTRAL
210
GUIDE HEAD RESTRAINT, WITH BUTTON
210
GUIDE HEADREST INTO BACKREST
220
FOLDING ARMREST
220
FOLDING ARMREST
220
FOLDING ARMREST
220
FOLDING ARMREST
220
FOLDING ARMREST
220
FOLDING ARMREST
220
FOLDING ARMREST
230
COVER ARMREST
230
COVER ARMREST
230
COVER ARMREST
230
COVER ARMREST, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805 AS OF MOD. YEAR 805, ORDER NEXT HIGHER ASSEMBLY....
235
LINE FOLD DOWN HEAD RESTRAINT
240
HOSE *** 30 MM
242
PLUG , F 140421 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE FROM F 140422 WITH CODE 806
244
DISTRIBUTOR DOUBLE
246
CLUTCH FOLD DOWN HEAD RESTRAINT
250
LOCKING MECHANISM HEAD RESTRAINT
255
BOLT LOCK TO CROSSMEMBER M6X11
260
BOLT ENGINE HOOD UPPER CATCH TO ENGINE HOOD M6X18, J 11373419981002
270
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
280
BRACKET REAR BACKREST OUTER RIGHT
280
BRACKET REAR BACKREST OUTER LEFT
310
BEARING SKI BAG FLOOR MOUNT, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805
320
RIVET BRACKET BEARING, E 01938620050630805 A 66602420040430805 F 59396620040531805 R 15626520040630805
