Поз.
Артикул
Описание
300
GUIDE CAMBER STRUT,RIGHT
300
GUIDE CAMBER STRUT,LEFT
310
HEXAGON HEAD BOLT SHOCK ABSORBER TO CONSOLE,BOTTOM M12X1.5X80
320
WASHER THRUST ARM TO WHEEL BEARING TO A 220 350 31 06
330
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
330
NUT BRACKET TO SIDE MEMBER M12X1.5
340
BOLT THRUST ARM TO WHEEL BEARING
350
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
350
NUT BRACKET TO SIDE MEMBER M12X1.5
400
GUIDE TENSION ROD LEFT
400
GUIDE TENSION ROD RIGHT
410
HEXAGON HEAD BOLT SHOCK ABSORBER TO CONSOLE,BOTTOM M12X1.5X80
420
WASHER THRUST ARM TO WHEEL BEARING TO A 220 350 31 06
430
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
430
NUT BRACKET TO SIDE MEMBER M12X1.5
500
GUIDE RIGHT THRUST ARM
510
BOLT THRUST ARM TO WHEEL BEARING
520
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
520
NUT BRACKET TO SIDE MEMBER M12X1.5
590
COVER THRUST ARM
600
THRUST ARM TRACK ROD LEFT
600
THRUST ARM RIGHT TRACK ROD
610
SCREW BEARING BRACKET TO CONSOLE
620
WASHER DUMPING PLATFORM MOUNTING
630
NUT SUPPORTING STRUT AT BRACKET AT LEFT BOTTOM M12X1.5, A 20131120
630
NUT BRACKET TO SIDE MEMBER M12X1.5
640
BOLT TIE ROD TO REAR SUBFRAME
650
BOLT TIE ROD TO REAR SUBFRAME
660
WASHER TIE ROD TO REAR SUBFRAME
670
PLATE PACKAGE TIE ROD TO REAR SUBFRAME
680
NUT TIE ROD TO REAR SUBFRAME
