Поз.
Артикул
Описание
25
COVERING CAB,REAR
25
COVERING CAB,REAR
33
COVERING CAB,REAR
70
BRACKET COVERING
168
SCREW PUMP TO BRACKET
168
SCREW , Replaced By: N304017006016
176
NUT , Replaced By: N913004006001
176
NUT PUMP TO BRACKET
179
SHEET METAL SCREW , Replaced By: N914031005208
179
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
198
SCREW , Replaced By: N304017006020
198
SCREW PUMP TO BRACKET M 6X20
198
SCREW LICENSE PLATE TO BRACKET
205
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
205
WASHER COMPRESSED AIR LINE TO BRACKET
212
NUT , Replaced By: N913004006001
212
NUT PUMP TO BRACKET
216
SHEET METAL SCREW BOOT TO CAB FLOOR
216
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
216
SHEET METAL SCREW BRACKET TO CAB
220
SCREW , Replaced By: N304017006020
220
SCREW LICENSE PLATE TO BRACKET
224
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
224
WASHER COMPRESSED AIR LINE TO BRACKET
228
NUT , Replaced By: N913004006001
228
NUT PUMP TO BRACKET
252
SUPPORT CAB, NOT USED
252
SUPPORT CAB
254
SCREW , Replaced By: N304017008021
254
SCREW PIPE CLAMP
256
WASHER EXHAUST MUFFLER TO STRAP
256
WASHER , Replaced By: N000125008443
258
NUT , Replaced By: N913004008001
258
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
262
BRACKET STRUT TO CROSS MEMBER
298
SCREW BRACKET TO SIDE MEMBER
298
SCREW , Replaced By: N304017010002
304
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
312
NUT , Replaced By: N304032010002
312
NUT BRACKET TO SUPPORT AND TO END PIECE
312
NUT
316
NUT STRAP TO BRACKET
316
NUT , Replaced By: N910113010000
356
RAIL , Replaced By: A6558900122
356
RAIL , Replaced By: A3878900522
356
RAIL (CONNECTING RAIL)
356
RAIL CAB SUSPENSION,REAR
362
COVERING CONNECTING RAIL
366
SCREW COVER PLATE TO COVER PLATE M 6 X 12
366
SCREW , Replaced By: N304017006018
370
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SHIM COVER PLATE TO CAB REAR PANEL, FOR USE WITH SHORT MERCEDES-BENZ CAB
999
COVERING CAB,REAR
999
COVER ENGINE COVERING, FOR USE WITH SHORT MERCEDES-BENZ CAB
