Поз.
Артикул
Описание
259
PUMP (HAND PUMP) WEBER
259
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
259
PUMP , Replaced By: A0005537901
259
PUMP (HAND PUMP) WEBER
259
PUMP , Replaced By: A0005536801
259
PUMP , Replaced By: A0005537901, +001A0015534205
259
PUMP (HAND PUMP) WEBER
259
PUMP , Replaced By: A0005534001
259
PUMP (HAND PUMP) WEBER
259
PUMP , Replaced By: A0005536501
259
PUMP (HAND PUMP) POWER PACKER,4 733732
287
PISTONWEBER,TO 000 553 40 01
287
PISTONTO 000 553 39 01,WEBER
287
PISTONTO 000 553 79 01,WEBER
287
PISTONTO 000 553 79 01,WEBER
301
VALVETO 000 553 79 01,WEBER
301
VALVEWEBER,TO 000 553 40 01
301
VALVETO 000 553 39 01,WEBER
301
VALVETO 000 553 88 01
301
VALVETO 000 553 39 01,WEBER
310
SEAL RING8X1 MM,HUNGER,TO 000 553 43 01, MODEL 416/417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB
315
SEAL RING PISTON TO 000 553 43 01
320
SEAL RING19X3 MM,HUNGER,TO 000 553 43 01, MODEL 416/417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB
325
SEAL RING19X3 MM,SAUER/HUNGER,TO 000 553 43 01, MODEL 416/417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB
329
SEAL RING20X10X7.5 MM,TO 000 553 27 01
364
CLAMPING SLEEVE4X32 MM,TO 000 553 23 01,WEBER,4 250875
371
CLAMPING SLEEVE4X12 MM,TO 000 553 23 01,
378
SEAL RING16X2.5 MM,TO 000 553 23 01,WEBER,4 250875
420
FILTER
420
FILTER
423
FILTERHUNGER
427
SCREW OIL FILLING HUNGER
427
SCREW , Replaced By: A0009901310
427
SCREW OIL FILLING TO 000 553 89 01
427
SCREW
427
SCREWTO 000 553 65 01,000 553 69 01,
427
SCREWTO 000 553 65 01,000 553 69 01,
441
GASKETHUNGER
441
GASKETWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
455
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
462
SCREW , Replaced By: N000000000190
462
SCREW
462
SCREW , Replaced By: N000912008201
462
SCREW BOX COVER TO 000 553 79 01,000 553 89 01
469
SEAL RINGTO 000 553 23 01,000 553 37 01,
476
SEAL RINGTO 000 553 23 01,000 553 37 01,,4 250876
483
FITTED WASHER
483
FITTED WASHER
490
LOCK RING
490
LOCK RING
504
SCREW
504
SCREW , Replaced By: A0009901310
504
SCREW OIL FILLING TO 000 553 89 01
504
SCREW
504
SCREW OIL FILLING HUNGER
569
GASKET KIT HAND PUMP
569
GASKET KIT , Replaced By: A0005502583
569
GASKET KIT HAND PUMP TO 000 553 37 01,000 553 39 01,WEBER
569
GASKET KIT HAND PUMP
569
GASKET KIT HAND PUMP
569
GASKET KIT HAND PUMP TO 000 553 68 01
569
GASKET KIT HAND PUMP
574
REPAIR KIT , Replaced By: A0005530880
574
REPAIR KIT , Replaced By: A0005502355
574
REPAIR KIT HAND PUMP TO 000 553 65 01,000 553 69 01,
581
REPAIR KIT VALVE TO 000 553 54 01,POWER-PACKER,4 733732
588
REPAIR KIT PISTON TO 000 553 54 01,POWER-PACKER,4 733732
595
BRACKET MANUAL PUMP
595
BRACKET HAND PUMP
602
BRACKET HAND PUMP
609
BRACKET HAND PUMP,4 705734
616
BRACKET , Replaced By: A6525530240
616
BRACKET HAND PUMP
617
BRACKET HAND PUMP
618
BRACKET AIR CLEANER SUPPORT
618
BRACKET HAND PUMP,5 114228
619
BRACKET HAND PUMP
621
SCREW BRACKET TO SIDE MEMBER
623
BRACKET HAND PUMP,5 942826
626
BRACKET , Replaced By: A3805450138
626
MOLDED PIECE HAND PUMP
630
SCREW , Replaced By: N304017010002
630
SCREW BRACKET TO SIDE MEMBER
630
SCREW REAR EXHAUST PIPE TO MUFFLER
630
SCREW REAR EXHAUST PIPE TO MUFFLER
630
SCREW REAR EXHAUST PIPE TO MUFFLER
630
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
630
SCREW BRACKET TO SIDE MEMBER
637
NUT , Replaced By: N910113010000
637
NUT STRAP TO BRACKET
644
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
651
SCREW , Replaced By: N304017008034
651
SCREW BRACKET TO CROSS CONNECTION STRUT
651
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
651
SCREW , Replaced By: N308676014020
651
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
651
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
658
NUT , Replaced By: N913004008001
658
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
658
NUT , Replaced By: N910113014001
658
NUT BRACKET TO SIDE MEMBER
662
SCREW , Replaced By: N308676012012
662
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
663
WASHER
664
NUT SUPPORT TO SIDE MEMBER
665
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
666
WASHER , Replaced By: N000125015019
666
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
667
NUT , Replaced By: N910113014001
667
NUT BRACKET TO SIDE MEMBER
675
SCREW , Replaced By: N304017008040
675
SCREW BRACKET TO SIDE MEMBER
678
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
680
SCREW CLAMP TO BRACKET AND TO PIPE
682
NUT , Replaced By: N913004008001
682
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
682
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
763
BRACKET , Replaced By: A3805450138
763
MOLDED PIECE HAND PUMP
999
GROMMET LINE THRU FRAME
999
WASHER HYDRAULIC CYLINDER TO CAB
999
WASHER HYDRAULIC CYLINDER TO CAB
999
PLATE HAND PUMP
999
WASHER HYDRAULIC CYLINDER TO CAB
999
BRACKET , UP TO CHASSIS 4 241133
999
BRACKET SUCTION LINE
999
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER
999
ANGLE LINE MOUNTING
999
BRACKET BRACKET TO SPRING SADDLE
