Поз.
Артикул
Описание
6
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
12
UNION NUT BUTT SCREW CONNECTION
18
GLAND LINE CONNECTION
24
HOSE , Replaced By: A0009872827
24
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
30
FITTING (PARTS KIT),LINE RUPTURE
30
FITTING , Replaced By: A0029906171
36
BANJO UNION , Replaced By: N915052009009
36
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
42
PLASTIC PIPE AERATION, ORDER BY THE METER
42
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
48
FITTING , Replaced By: A0029905971
48
FITTING (PARTS KIT),LINE RUPTURE
54
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
60
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
66
LOOM TIE LINE MOUNTING 280 MM
66
LOOM TIE LINE MOUNTING
90
AIR DEHYDRATORWABCO,5 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
90
AIR DEHYDRATORKNORR, Replaced By: A0024317115
90
AIR DEHYDRATORBOSCH,5 937586
90
AIR DEHYDRATORWABCO
90
AIR DEHYDRATORKNORR,5 937586, Replaced By: A0024317015
90
AIR DEHYDRATORBOSCH
91
AIR CLEANER COMPLETE TO BOSCH,KNORR
91
AIR CLEANER , Replaced By: A0004293695
91
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
93
SEAL RINGWABCO
94
GASKET KIT SEAL RINGS KNORR,5 937586
94
GASKET KITWABCO
96
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
102
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
108
O-RING CHECK VALVE TO AIR RESERVOIR
114
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
120
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
126
O-RING CHECK VALVE TO AIR RESERVOIR
132
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
138
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
144
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
150
HOLLOW SCREW HEATING CONNECTION
156
SEAL RING LINE CONNECTION
162
BRACKET ANTI-FREEZE DEVICE
168
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
168
SCREW , Replaced By: N308676012012
174
LOCK WASHER FITTING TO BRACKET
180
SCREW BRACKET TO SIDE MEMBER
186
NUT , Replaced By: N910113010000
186
NUT STRAP TO BRACKET
999
FILTER ELEMENT , Replaced By: A0004293795
999
CONNECTOR 90 DEG. OFFSET
999
REPAIR KIT PRESSURE REGULATOR KNORR
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
HEATERKNORR
999
HEATERWABCO
999
FILTER , Replaced By: A0004291297
999
FITTING HYDRAULIC PUMP SUCTION PIPE
999
NUT EXHAUST PIPE TO SIDE MEMBER
999
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
999
BRACKET ANTI-FREEZE DEVICE, NOT USED
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
NUT , Replaced By: N913004008001
