Поз.
Артикул
Описание
5
PRESSURE REGULATORWABCO
5
PRESSURE REGULATORBOSCH,241, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
8
REPAIR KIT SEAL RING BOSCH,209
8
REPAIR KIT PRESSURE REGULATOR WABCO
11
SCREW , Replaced By: N910105008043
11
SCREW REAR AXLE REGULATING SOLENOID VALVE
14
NUT , Replaced By: N913004008001
14
NUT BRACKET TO BRACKET
18
BRACKET PRESSURE REGULATOR
20
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
20
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
20
SCREW , Replaced By: N910105008043
23
NUT BRACKET TO BRACKET
23
NUT , Replaced By: N913004008001
26
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
28
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
29
O-RING CHECK VALVE TO AIR RESERVOIR
31
HOLLOW SCREW HEATING CONNECTION
33
SCREW PLUG , Replaced By: N000908012009
35
SEAL RING LINE CONNECTION
36
ELBOW FITTING ,5 433281
37
NUT CHECK VALVE TO AIR RESERVOIR
38
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
41
CLAMP , Replaced By: N000000000667
44
AIR DEHYDRATORWABCO,5 937586 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
44
AIR DEHYDRATORBOSCH,5 937586
44
AIR DRIERKNORR,5 937586
44
AIR DEHYDRATORKNORR,5 937586, Replaced By: A0024317015
47
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
47
AIR CLEANER COMPLETE TO BOSCH,KNORR
50
SEAL RINGWABCO
53
GASKET KIT SEAL RINGS KNORR,5 937586
53
GASKET KITBOSCH
53
GASKET KITWABCO
56
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
59
LOCK WASHER FITTING TO BRACKET
62
BRACKET AIR DEHYDRATOR,5 433280
65
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
65
SCREW SUPPORT TO CROSS MEMBER M 10X28
68
NUT , Replaced By: N910113010000
68
NUT EXHAUST PIPE TO SIDE MEMBER
77
ELBOW FITTING ,5 433281
80
NUT INTERMEDIATE SPEED STOP
83
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
86
O-RING CHECK VALVE TO AIR RESERVOIR
92
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
92
FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
93
HOLLOW SCREW HEATING CONNECTION
94
SEAL RING LINE CONNECTION
94
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
CONNECTOR 90 DEG. OFFSET
101
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
101
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820, Replaced By: A0034315006
104
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE
107
SCREW , Replaced By: N304017008016
107
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
110
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
116
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
119
ELBOW FITTING ,5 433281
122
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
122
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
125
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
128
O-RING CHECK VALVE TO AIR RESERVOIR
131
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
134
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
137
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
140
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
140
HOLLOW SCREW LINE CONNECTION
143
SEAL RING LINE CONNECTION
146
NUT COMBINATION CYLINDER,CONNECTION: "12"
149
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
149
VALVE EMERGENCY RELEASE VALVE,CONNECTION: "23"
