Поз.
Артикул
Описание
6
FINE CONTROL , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 314,352387047 401,402,403829142 421,422,423829142 442,443829142 404,424,444017412 407,427,447058665, Replaced By: A0000602698
6
FINE CONTROL , Replaced By: A0000602398
8
TIMING LEVERTO 000 060 13 98/12 98
9
ANGLETO 000 060 13 98
10
SPACER RING BRACKET TO INJECTION PUMP GOVERNOR HOUSING
14
SCREW IN CASE OF SUBSEQUENT INSTALLATION
14
SCREW COVER PLATE TO COVER PLATE M 6 X 12
14
SCREW LICENSE PLATE TO BRACKET
14
SCREW , Replaced By: N304017006018
14
SCREW , Replaced By: N304017006020
16
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
16
LOCK WASHER BRACKET TO STEERING COLUMN END
20
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
25
LEVER FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
30
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
35
BANJO UNION FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
40
SEAL RING CONNECTION: 1,4 719029
45
SPRING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6769930010
50
SCREW LEVER TO GOVERNOR
50
SCREW COVER PLATE TO BRACKET
55
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
60
WASHER LEVER TO GOVERNOR
60
WASHER LEVER TO GOVERNOR
65
GASKET LEVER TO GOVERNOR
70
SPRING , Replaced By: A3529931910
75
BRACKET , Replaced By: A3140100140
75
BRACKET , Replaced By: A3140180240
80
FITTING
85
SCREW PLUG FUEL TANK
85
SCREW PLUG , Replaced By: N007604014110
90
HOSE LINE , Replaced By: A0089975482
90
HOSE LINE , Replaced By: A0089975482
90
HOSE
90
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
95
CLAMP
105
STOP RELEASE SPRING
110
BANJO UNION , Replaced By: N000000000363
110
BANJO UNION FUEL LINES AND BREATHING
115
FITTING RETURN
120
NUT. UNION NUT RETURN
125
HOLLOW SCREW HAND PUMP,K 169122
125
HOLLOW SCREW , Replaced By: N915036010109
130
SEAL RING FUEL LINE TO FEED PUMP
135
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
140
STUD
999
FINE CONTROL12 V
999
LEVER INJECTION PUMP CONTROL LEVER
999
BRACKET FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
999
BRACKET
999
HOSE
