Поз.
Артикул
Описание
5
CRANKCASE WITH CYLINDER LINERS, Replaced By: A4570101705
5
CRANKCASE WITH CYLINDER LINERS
5
CRANKCASE , Replaced By: A4570100505
5
CRANKCASE , Replaced By: A4570101305
5
CRANKCASE , Replaced By: A4570101905
5
CRANKCASE WITH CYLINDER LINERS, Replaced By: A4570101805
8
DOWEL PIN CRANKSHAFT BEARING CAP
11
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE M 18X2X153/35 MM
11
SCREW , TO BE ADAPTED DURING ASSEMBLY
11
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE M 18X2X153/35 MM
14
CAMSHAFT BEARING PARTS KIT
14
CAMSHAFT BEARING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 761801, Replaced By: A4570500151
17
CAMSHAFT BEARING , Replaced By: A4570511510
17
CAMSHAFT BEARING WITH COLLAR
20
CAMSHAFT BEARING STANDARD 35 MM
20
CAMSHAFT BEARING STANDARD 35 MM
23
CAMSHAFT BEARING STANDARD 30 MM
23
CAMSHAFT BEARING , Replaced By: A4570511910
26
SCREW PLUG OIL-FILTER/LONGITUDINAL-DUCT CONNECTION BORE
29
SCREW PLUG OIL-FILTER/LONGITUDINAL-DUCT CONNECTION BORE
32
SCREW PLUG OIL COOLER,5 360280
33
EXPANSION PLUG , Replaced By: A4039970620
35
SEAL RING
38
SCREW PLUG (OIL LEVEL INDICATOR)
39
EXPANSION PLUG , Replaced By: A4039970620
41
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,OIL PUMP
41
SEAL RING
44
SCREW PLUG OIL COOLER,5 360280
44
SCREW PLUG , Replaced By: N000908022011
45
EXPANSION PLUG , Replaced By: A4039970620
47
SEAL RING
47
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,FAN SIDE
53
EXPANSION PLUG
53
EXPANSION PLUG TO LOCK LONGITUDINAL COOLING WATER DUCT 62.1 MM
53
EXPANSION PLUG TO LOCK LONGITUDINAL COOLING WATER DUCT 50.1 MM
56
SCREW PLUG OIL COOLER,5 360280
56
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
56
SCREW PLUG , Replaced By: N000908014009
57
EXPANSION PLUG
59
SEAL RING VALVE TO VALVE,K 025179
59
SEALING RING OIL LINE TO CYLINDER CRANKCASE
59
SEALING RING
59
SEALING RING. SEAL RING ENGINE BREATHING
71
BALL FUEL BORE COVER,UNIT PUMP SIDE
71
BALL SHIFTING CYLINDER
71
BALL FASTENER FUEL BORE FAN SIDE
71
BALL INTERMEDIATE FLANGE
71
BALL , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
71
BALL FRONT AND REAR 14.288 MM
72
OIL NOZZLE LUBRICATION OF P.T.O.
72
OIL NOZZLE PTO BORE HOLES COVER
73
SEALING RING OIL LINE TO CYLINDER CRANKCASE
74
SCREW PLUG OIL PASSAGE PLUG
75
THREADED PIN PROPELLER SHAFT
77
BALL , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
80
SCREW PLUG OIL COOLER,5 360280
83
SEAL RING
86
CYLINDER PIN
89
THROTTLE FUEL BORE COVER,UNIT PUMP SIDE
95
CYLINDRICAL PIN TIMING CASE FIXING 16X24
98
CYLINDRICAL PIN TIMING CASE FIXING 16X24
113
OIL NOZZLE , Replaced By: A4571801243
113
OIL NOZZLE ,051236, Replaced By: A4571801443, +001A4609900063
113
OIL NOZZLE PISTON COOLING
116
HOLLOW SCREWB10
116
HOLLOW SCREW OIL SPRAY NOZZLE TO CYLINDER CRANKCASE
119
OIL NOZZLE CAM LUBRICATION
119
OIL NOZZLE CAM LUBRICATION
119
OIL NOZZLE CAM LUBRICATION BANDABLAUF 12/07, ZAM 441/07, C 74310, EXHAUST STOCK OF OLD PARTS UP TO ENGINE 131006, Replaced By: A4571801843
119
OIL NOZZLE CAM LUBRICATION, Replaced By: A4601800643
119
OIL NOZZLE CAM LUBRICATION
119
OIL NOZZLE CAM LUBRICATION
122
HOLLOW SCREW BREATHER LINE TO HEAT EXCHANGER
125
SENDER UNIT TEMPERATURE SENDER UNIT
125
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT
128
SEALING RING
206
GASKET KIT CYLINDER CRANKCASE, NOT USED
206
GASKET KIT CYLINDER CRANKCASE
206
GASKET KIT CYLINDER CRANKCASE
999
EXPANSION PLUG CAP FOR OIL DUCT ON UNIT PUMP SIDE
999
CYLINDRICAL PIN
