Поз.
Артикул
Описание
10
OIL PAN
10
OIL PAN
50
SCREW PLUG, FILLING. SCREW PLUG LONGITUDINAL OIL DUCT COVER ON OIL COOLER SIDE M16X1,5
50
SCREW PLUG
60
SEAL RING
60
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
110
GASKET OIL PAN TO CYLINDER CRANKCASE
110
GASKET OIL PAN TO CYLINDER CRANKCASE
110
GASKET OIL PAN TO CYLINDER CRANKCASE, Replaced By: A4570140522
110
GASKET OIL PAN TO CYLINDER CRANKCASE
115
SEALANT TIMING CASE TO CYLINDER CRANKCASE
130
SCREW. HEXAGON HEAD BOLT OIL PAN TO CYLINDER CRANKCASE M8X35
140
SCREW FAN TO CRANKSHAFT PULLEY
390
OIL FILLER NECK
400
CAP OIL REFILLING
410
GASKET , Replaced By: A1020180080
420
GASKET OIL FILLER NECK TO OIL PAN
430
SCREW STOP TO BATTERY CASE
440
BRACKET BREATHER PIPE
450
SCREW CABLE HARNESS MOUNTING
460
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
470
OIL DIPSTICK
480
SEAL RING
500
GUIDE TUBE OIL DIPSTICK
530
BRACKET FUEL LINE FROM FILTER TO HEAT EXCHANGER
550
SCREW STOP TO BATTERY CASE
560
NUT ENGINE MOUNTING M8
570
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
600
FLANGE
660
GASKET OIL FILLER NECK
670
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
