Поз.
Артикул
Описание
5
PRESSURE REGULATOR , Replaced By: A0024313406
25
T-FITTING
25
T-FITTING COMPRESSED AIR VALVE CONNECTION
30
NUT CHECK VALVE TO AIR RESERVOIR
35
O-RING CHECK VALVE TO AIR RESERVOIR
40
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
40
THRUST RING CHECK VALVE TO AIR RESERVOIR
45
VALVE (OVERFLOW VALVE)
45
VALVE OVERFLOW VALVE WABCO
45
VALVE (OVERFLOW VALVE)
45
VALVE
45
VALVE
45
VALVE
45
VALVE (OVERFLOW VALVE)
45
VALVE
50
VALVE
55
DIAPHRAGMTO 000 429 63 44
55
DIAPHRAGMTO 344 429 73 44
55
DIAPHRAGM
57
VALVE SEAT RINGWABCO,5 433388
60
SPRINGTO 000 429 63 44,000 429 59 44
65
SPRING RETAINERTO 000 429 63 44,000 429 59 44
70
REPAIR KITTO 001 429 52 44
70
REPAIR KITBOSCH
70
REPAIR KITTO 000 429 63 44,000 429 59 44
80
ELBOW FITTING AT OVERFLOW VALVE
80
ELBOW FITTING AT OVERFLOW VALVE
85
NUT CHECK VALVE TO AIR RESERVOIR
90
THRUST RING CHECK VALVE TO AIR RESERVOIR
90
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
95
O-RING CHECK VALVE TO AIR RESERVOIR
100
LOCK NUT OVERFLOW VALVE
105
LOCKING CONE OVERFLOW VALVE
110
LINE FROM OEVERFLOW VALVE TO FOOT OPERATED VALVE
110
LINE
110
LINE FROM OEVERFLOW VALVE TO FOOT OPERATED VALVE
110
LINE FROM OEVERFLOW VALVE TO FOOT OPERATED VALVE
115
UNION NUT
120
GLAND , Replaced By: A0019901667
130
CLAMP COMPRESSED AIR LINE TO SIDE MEMBER
135
VALVE"WESTINGHOUSE"
135
VALVE"WABCO DO BRASIL"
140
HANDLETO 000 434 24 01
165
FITTING , Replaced By: A0029906071
170
SEAL RING LINE CONNECTION
175
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
180
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
185
NUT , Replaced By: N080705026003
190
LINE
190
LINE
195
UNION NUT
200
GLAND , Replaced By: A0019901667
210
CONNECTION FITTING , Replaced By: A0039979172
215
HOSE PRESSURE GAUGE
215
LINE
220
UNION NUT
225
GLAND , Replaced By: A0019901667
230
SEAL RING LINE CONNECTION
235
FITTING , Replaced By: A0029906071
245
CLAMP ,K 147121, Replaced By: N000000000319
245
CLAMP , Replaced By: N916016008200
250
SCREW CONTACTOR
255
LOCK WASHER LINE MOUNTING
260
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
265
CLAMP BRAKE LINE TO SIDE AND CROSS MEMBERS
270
PLATE
275
SCREW CONTACTOR
280
LOCK WASHER LINE MOUNTING
285
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
315
CLAMP BREATHER LINE TO REAR AXLE
315
CLAMP COMPRESSED AIR LINE TO SIDE MEMBER
320
SCREW OIL TANK TO BRACKET
320
SCREW FUEL LINE TO BRACKET
325
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
325
LOCK WASHER CLAMP TO BRACKET
330
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
330
NUT BALL PIVOT TO LEVER
999
DIAPHRAGM , Replaced By: A0004290745
999
VALVE , Replaced By: A0014295244
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , Replaced By: A0004342401
999
RUBBER PAD
999
CLAMP , Replaced By: A3604300143
999
DOUBLE FITTING , Replaced By: A0019972872
