Поз.
Артикул
Описание
10
AXLE HOUSING REAR AXLE CENTER ASSEMBLY W/O FLANGE 1:2.65
20
END COVER
30
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
40
VENTILATION NECK , Replaced By: A1663510265
50
BREATHER
60
SCREW PLUG BELL HOUSING
80
SEAL RING INTERIOR FLANGE, IMPORTANT: SEALING RING AND PROTECTIVE RING MUST ALWAYS BE EXCHANGED TOGETHER!
100
NUT FLANGE TO DRIVE PINION
110
JOINT FLANGE PROPELLER SHAFT 120 MM
120
SEAL RING DRIVE PINION
130
ADAPTER REAR AXLE TRANSVERSE GUIDE,LEFT
140
ADAPTER REAR AXLE TRANSVERSE GUIDE,RIGHT
150
END COVER TO REAR AXLE COVER
160
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION
