Поз.
Артикул
Описание
300
SCREW LICENSE PLATE TO BRACKET
300
PURGE VALVE
305
WASHER COMPRESSED AIR LINE TO BRACKET
310
BRACKET ON SPRING DOME,LEFT, A 02918420110908
310
BRACKET ON SPRING DOME,LEFT, A 02918320110908
320
NUT , Replaced By: N913023006001
330
PURGE LINE SEPARATING POINT TO PURGE VALVE
330
LINE PURGE VALVE TO PURGE LINE
340
PURGE LINE REGENERATION VALVE TO ENGINE
350
BRACKET ATTACHMENT
375
HOSE FROM ACTIVATED CHARCOAL FILTER TO REGENERATION VALVE
380
HOSE CLAMP HOSE ATTACHMENT
385
CLAMP RETURN LINE TO FILTER 15.5-17.5 MM
420
CLAMP RETURN LINE TO FILTER 15.5-17.5 MM
430
HOSE FROM ACTIVATED CHARCOAL FILTER TO REGENERATION VALVE
440
HOSE CLAMP HOSE ATTACHMENT
550
PURGE LINE BETWEEN ACTIVATED CHARCOAL FILTER AND REGENERATION VALVE, A 02334820090220
