Поз.
Артикул
Описание
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH", 14V, 55A
10
ALTERNATOR14V 35A, MODEL 343.919.000 UP TO ENGINE 154149,MODEL 344.919.000 UP TO ENGINE 822956
10
ALTERNATOR , Replaced By: A0071542302, +001A0001557118
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 28 V 55 A
10
ALTERNATOR28V 35A
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 14V 35A, MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY
10
ALTERNATOR14 V 35 A,822956
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH", 14V/90A
10
ALTERNATOR *** 14V 23A
10
ALTERNATOR28V 35A, WITH TERMIANL "W"
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH" 28V/80A
10
ALTERNATOR , Replaced By: A3431507350
10
ALTERNATOR
10
ALTERNATOR , Replaced By: A3441508050
10
ALTERNATOR , Replaced By: A3441507450
10
ALTERNATOR , Replaced By: A3441507850
10
ALTERNATOR , Replaced By: A3761507750
10
ALTERNATOR , Replaced By: A3761507850
10
ALTERNATOR WITH PULLEY, LESS REGULATOR 12 V/55 A
10
ALTERNATOR WITH PULLEY
10
ALTERNATOR , Replaced By: A3761508350
10
ALTERNATOR , Replaced By: A3761508350
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "BOSCH" 28V/80A, Replaced By: A0131545002
10
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY "VALEO", 14V/55A
15
ALTERNATOR14V/65A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
15
ALTERNATOR , Replaced By: A0071542602
15
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY TO 343 150 73 50
15
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY "VALEO",14V/55A TO 343 150 87 50
20
SCREW
20
SCREWTO 344 154 72 01,75 01
20
SCREW
20
SCREW , MODEL 343.919.000 UP TO ENGINE 154149,MODEL 344.919.000 UP TO ENGINE 822956
20
SCREWTO 344 150 71 50,80 50,344 154 75 01
20
SCREW ,154149
20
SCREWTO 345 154 71 01
20
SCREW , Replaced By: A0009908321
20
SCREW , Replaced By: A0009909621
20
SCREWTO 344 150 73 50
20
SCREW HOUSING
20
SCREW DRIVE END BEARING,COMMUTATOR BEARING
20
SCREW , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
20
SCREW , Replaced By: A0019900321
20
SCREWTO 344 154 71 02
20
SCREWTO 376 150 87 50
20
SCREW
20
SCREW , Replaced By: A0019900821
20
SCREW , Replaced By: A0009909821
20
SCREW
20
SCREW , Replaced By: A0019906420
25
LOCK WASHERTO 376 150 74 50
25
LOCK WASHERTO 344 150 73 50
30
NUT
35
BALL BEARING , Replaced By: A0079816625
35
BALL BEARINGTO 007 154 27 02, 009 154 07 02
35
GROOVED BALL BEARING FRONT
35
TAPERED ROLLER BEARING FRONT TO 344 154 71 01,72 01,75 01, NOT USED
35
GROOVED BALL BEARING
35
BALL BEARING
35
BALL BEARING , Replaced By: A0059812225
35
BALL BEARING DRIVE END BEARING TO 008 154 31 02
35
BALL BEARING FRONT TO 345 150 70 50,345 154 71 01
35
TAPERED ROLLER BEARINGTO 344 150 71 50,73 50,80 50
35
BALL BEARINGTO 344 154 71 02
35
SPACER WASHER
35
BALL BEARING SLIP RING SIDE TO 004 154 25 02
35
BALL BEARING DRIVE END BEARING, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 686
37
SCREENING PLATE
40
RING
40
RINGTO 007 154 27 02
40
RINGTO 376 150 74 50
45
RINGTO 366 150 07 50, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
45
RING
50
SEAL RINGTO 005 154 34 02
55
COVER
55
COVERTO 376 150 87 50
55
COVER , Replaced By: A0001540767
60
BALL BEARING , Replaced By: A0049811925
60
BALL BEARING , Replaced By: A0089811225
60
BALL BEARINGTO 007 154 27 02, 009 154 07 02
60
BALL BEARING SLIP RING SIDE TO 376 150 87 50
60
BALL BEARINGTO 344 154 71 02
60
BALL BEARING FRONT AND REAR
60
BALL BEARING REAR
60
BALL BEARING SLIP RING SIDE TO 004 154 25 02
60
BALL BEARINGTO 005 154 34 02
60
BALL BEARING SLIP RING SIDE, Replaced By: A0079819025
65
ROTOR
65
ROTOR ,822956
65
ROTORTO 345 154 71 01
65
ROTORTO 344 150 71 50,80 50,344 154 75 01
65
ROTOR
65
ROTORTO 007 154 26 02
65
ROTORTO 366 150 07 50, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
65
ROTOR
65
ROTORTO 376 150 87 50
65
ROTORTO 366 150 06 50, NOT USED
65
ROTORTO 345 150 70 50
65
ROTOR
65
ROTOR , Replaced By: A0001545015
65
ROTOR , Replaced By: A0001546015
65
ROTOR , Replaced By: A0001545715
68
RINGTO 000 154 16 57
70
COIL EXCITER
70
COILTO 344 150 74 50,78 50
70
COILTO 366 150 06 50, NOT USED
70
COIL EXCITER TO 343 150 73 50
70
COIL
70
COILTO 366 150 07 50, APPLICABLE TO ALTERNATOR HAVING BOSCH NO.0 120 469 982
70
EXCITER COIL
70
COILTO 345 150 70 50
70
COIL EXCITER TO 376 150 87 50
70
COILTO 345 154 71 01
70
COILTO 007 154 26 02
70
EXCITER COIL , Replaced By: A0001518855
70
COIL , Replaced By: A0001545325
70
COIL , Replaced By: A0001547125
70
COIL , Replaced By: A0001546625
70
COIL , Replaced By: A0001546725
70
COIL , Replaced By: A0001548825
70
COIL , Replaced By: A0001546925
70
EXCITER COIL , Replaced By: A0001517155
75
BEARING , Replaced By: A0001514149
75
CONNECTOR , Replaced By: A0001541818
75
CONNECTOR , Replaced By: A0001541818
75
BEARING
75
COVERTO 344 150 71 50,80 50,344 154 75 01
75
BEARING COVER
75
CONNECTOR FRONT TO 345 154 71 01
75
BEARINGTO 007 154 26 02
75
BEARING COVER ,822957
75
CONNECTOR ,154149
75
BEARING DRIVE END BEARING
75
BEARINGTO 007 154 26 02
80
BUSHINGTO 007 154 26 02
80
COLLARED BUSHING. BUSHING
85
SCREW
90
LOCK WASHER
95
SEAL RING , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
100
RECTIFIER
100
RECTIFIERTO 376 150 78 50
100
RECTIFIER
100
RECTIFIER , Replaced By: A0001545716
100
RECTIFIERTO 344 150 73 50
100
RECTIFIERTO 005 154 45 02,006 154 86 02
100
RECTIFIER
100
RECTIFIER , Replaced By: A0011541516
100
RECTIFIERTO 366 150 06 50, NOT USED
100
RECTIFIERTO 376 150 87 50
100
RECTIFIER , Replaced By: A0001544716
100
RECTIFIER , Replaced By: A0011541116
100
RECTIFIER , Replaced By: A0001545116
100
RECTIFIER , Replaced By: A0011541616
100
RECTIFIER , Replaced By: A0011542116
100
RECTIFIER , Replaced By: A0011542116
105
SCREW
105
SCREW
105
SCREW RECTIFIER, NOT USED
110
LOCK WASHERTO 344 150 74 50,78 50
115
COVERTO 376 150 78 50,154150
115
COVERTO 344 150 71 50,80 50,344 154 75 01
115
BEARING SLIP RING SIDE
115
BEARINGTO 344 154 71 02
115
BEARINGTO 007 154 26 02
115
BEARINGTO 376 150 80 50
115
BEARINGTO 345 154 71 01
115
BEARING , Replaced By: A0001542449
115
BEARING BODYTO 376 150 87 50
120
CONDENSER , Replaced By: A0011566701
120
CONDENSERTO 345 154 71 01
120
CONDENSER
120
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
122
PIN
125
SCREW CONDENSER TO ALTERNATOR
125
SCREW , USED WITH AIR BRAKE
125
SCREW
130
SPRING WASHER HEATER PLUG CABLE HARNESS
130
LOCK WASHERTO 376 150 74 50
135
BRUSH HOLDERTO 344 154 71 02
135
BRUSH HOLDERTO 345 150 70 50
140
GASKETTO 007 154 26 02
140
GASKET
145
REGULATORTO 007 154 27 02
145
REGULATOR AND CUT-OUTTO 343 150 73 50
145
REGULATOR AND CUT-OUT
145
REGULATORTO 007 154 26 02
145
REGULATOR AND CUT-OUTTO 376 150 87 50
145
REGULATOR AND CUT-OUT , Replaced By: A0001541705
145
REGULATOR AND CUT-OUTTO 005 154 32 06
145
REGULATOR AND CUT-OUTTO 344 150 73 50
145
REGULATOR AND CUT-OUT , Replaced By: A0001541805
145
REGULATOR AND CUT-OUT
145
REGULATOR AND CUT-OUT , Replaced By: A0001541805
145
REGULATOR AND CUT-OUT , Replaced By: A0001541805
150
CARBON BRUSH SET , Replaced By: A0001549514
150
CARBON BRUSH SET , Replaced By: A0001549814
150
CARBON BRUSH SET , Replaced By: A0001548114
150
CARBON BRUSH SETTO 344 154 71 02
150
CARBON BRUSH SET
