Поз.
Артикул
Описание
8
INTAKE MANIFOLD
16
THREADED INSERT
24
SCREW PLUG IN PLACE OF SPEEDOMETER DRIVE
32
SEAL RING SPEEDOMETER DRIVE
40
INSTRUCTION PLATE
48
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
56
SCREW VALVE TO BRACKET M 8X55
56
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
56
SCREW ANTI-FREEZE PUMP TO BRACKET,950272
56
SCREW , Replaced By: N304017008030
56
SCREW , Replaced By: N304017008043
64
FLANGED PIPE SOCKET INTAKE MANIFOLD
64
FLANGED PIPE SOCKET INTAKE MANIFOLD
72
GASKET , Replaced By: A3601410280
80
SPRING WASHER , Replaced By: N000137008212
80
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
88
SCREW PIPE CLAMP
88
SCREW MOUNTING PARTS M8 X 170
88
SCREW , Replaced By: N304017008021
96
MOLDED PIECE , Replaced By: A4032010108
104
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
104
LOOM TIE , Replaced By: N916017025000
999
GASKET
999
SCREW , Replaced By: N304014008021
